VEHICLE PREPARATION
20. Once satisfied with the cut of the flare,
replace the headlight and the grill.
21. Clean the flare where it has been cut
and attach the plastic side moulding to
the flare.
22. Cut the plastic side moulding with a
Stanley knife along the back edge of the
flare.
23. It is recommended that the lower portion
of the bodywork below the flare cut off
be painted black. Clean the surface with
prep wash then mask the surrounding
area.
If fog lights not fitted go to step 26
24. Using a TORX bit, remove the fog lights
from the bumper bar and keep the six
retaining screws.
25. Remove the fog light wiring loom from
the bumper bar.
