FITTING REQUIREMENTS
REQUIRED TOOLS FOR FITMENT OF PRODUCT:
POWER DRILL WITH 8 & 10MM BITS SCREWDRIVER SET
METRIC SOCKET SET & SPANNERS KEY HOLE SAW
TORX BIT SET SHARP KNIFE & WHITE MARKER
SENSOR SAFE SILICONE
HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT
:
Protective eyewear Hearing protection
NOTE: ‘WARNING’ notes in the fitting procedure relate to OHS situations, where to avoid a potentially
hazardous situation it is suggested that protective safety gear be worn or a safe work procedure be
employed. If these notes and warnings are not heeded, injury may result.
FASTENER TORQUE SETTINGS:
SIZE Torque Nm Torque lbft
M6 9Nm 7lbft
M8 22Nm 16lbft
M10 44Nm 32lbft
M12 77Nm 57lbft
