Removal of bumper – ARB 3415120 User Manual
Page 4
Last Rev Date: 17 SEPTEMBER 2008
Page 4 of 20
Fitting instructions# 3783312
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
REMOVAL OF BUMPER
1.
Remove number plate
2.
Remove number plate mount bracket
3.
Remove inner guard bumper retaining
screws three per side using M4 hex key
4.
Remove lower trim panel sets each side
which attach to bumper and engine
protective plate area then set aside, they
will not be reused.
