56
CHG REPLACEMENT PARTS LIST
KEY DESCRIPTION
CHG150 CHG225
BURNHAM
PART #
QUANTITY
BURNHAM
PART #
QUANTITY
3 #8-32 x 1/4” H.W.H. Screw 100401-01 2 100401-01 2
4 Front Door Panel 100402-01 1 100402-02 1
5 #6-32 Hex Nylon Insert LockNut 100403-01 4 100403-01 4
6 Control Chassis Assembly 100404-01 1 100404-01 1
7 .125” ID x .250”OD Silicone Tubing 100405-01 1.25’ 100405-01 1.25’
8 .125” ID x .250”OD Silicone Tubing 100406-01 5.0’ 100406-01 5.1’
9 Vestibule Door Seal - Horizontal 100407-01 4 100407-02 4
10 Vestibule Door Seal - Vertical 100408-01 2 100408-01 2
11 #10 x 3/4 Hex Wsh Hd Screw 100409-01 22 100409-01 22
12 Lower Vestibule Door 100410-01 1 100410-02 1
13 U Type Speed Nut 100411-01 22 100411-01 22
14 Vinyl Grommet - .25” ID (For .875” Hole) 100412-01 1 100412-01 1
15 Miniature Hose Fitting 1/8” Barbed to 10-32 Male Thread 100413-01 2 100413-01 2
16 10-32 SS Hex Nut 100414-01 1 100414-01 1
17 #6-32 x 1/4” Hex x 1/2” Long Male-Female Steel Standoff 100415-01 4 100415-01 4
18 #6 -32 x 3/4 “ H.W.H. Screw 100416-01 4 100416-01 4
19 Center Vestibule Door 100417-01 1 100417-02 1
20 #10 x 1/2 Hex Wsh Hd Screw 808600492 25 808600492 26
21 #10 Flat Washer 80860635 4 80860635 4
22 Inspection Port Window 100420-01 1 100420-01 1
23 Upper Vestibule Door 100421-01 1 100421-02 1
24 Partition 100422-01 1 100422-02 1
25 #10 x 1/2 Truss Hd Screw 100423-01 21 100423-01 21
26 Shutter Bushing for .875” Hole 100424-01 2 100424-01 2
27 Flat Wire Clip (Ribbon Cable) 100425-01 2 100425-01 2
28 Right Side Panel Assembly 100426-01 1 100426-01 1
29 5/16 ID Cable Clamp 100427-01 1 100427-01 1
30 Left Side Panel Assembly 100428-01 1 100428-01 1
31 3/4” Boiler Drain Valve 100429-01 1 100429-01 1
32 1-1/4” x 3/4” x 1-1/4” Bk Reducing Tee 806601109 1 806601109 1
33 Vinyl Grommet - .1.625” ID (For 2.625” Hole) 100431-01 2 100431-01 2
34 M6 x 1.0 x 12 Hex Hd Cap Screw 100432-01 2 100432-01 2
35 Trap Tubing (Condensate Drain) 100433-01 3.5’ 100433-01 3.5’
36 3/8-16 x 5/8 Hex Hd Cap Screw 100434-01 4 100434-01 4
37 3/8 Flat Washer 80860618 4 80860618 4
38 1-1/4” x 6” Bk Nipple 6066017 1 6066017 1
39 1-1/4” x 19” Bk Nipple 100437-01 1 100437-01 1
40 2” ID x 2.25” OD Polypro/Rubber Duct Hose 100438-01 19-1/2” 100438-01 14-3/4”
41 SAE # 32 Hose Clamp 100439-01 1 100439-01 1
43 #10-24 x 3/8” Hex Wshr Hd Type F 100440-01 NA 100440-01 1
44 Aluminum Cable Tie Mount 100441-01 7 100441-01 9
45 Vinyl Grommet - .825” ID (For 1.625” Hole) 100442-01 1 100442-01 1
46 1/4-20 x 1/2 Self Tapping Screw 100443-01 4 100443-01 4
