—40—
HEAT PUMP HEATING PERFORMANCE continued
See notes on page 41.
INDOOR
AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES °F
–3 7 17 27 37 47 57 67
EDB CFM
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Total Int* KW† Total Int* KW† Total Int* KW† Total Int* KW† Total Int* KW† Total Int* KW† Total Int* KW† Total Int* KW†
698BNX060000 Outdoor Section With FV4ANB006 Indoor Section - High Speed
65
1500 22.28 20.50 3.11 28.85 26.51 3.46 36.13 32.95 3.83 44.59 39.60 4.25 53.95 49.09 4.69 61.58 61.58 4.98 63.60 63.60 5.05 65.09 65.09 5.11
1750 22.92 21.09 3.19 29.57 27.17 3.53 36.99 33.73 3.89 45.58 40.48 4.31 55.08 50.12 4.68 57.21 57.21 4.76 58.50 58.50 4.80 60.23 60.23 4.85
2000 23.45 21.57 3.27 30.16 27.71 3.61 37.74 34.41 3.97 46.34 41.16 4.39 52.45 47.73 4.58 54.04 54.04 4.64 55.00 55.00 4.66 56.28 56.28 4.69
2250 23.97 22.05 3.36 30.61 28.12 3.68 38.43 35.04 4.06 47.47 42.16 4.42 50.77 46.20 4.55 51.70 51.70 4.57 51.69 51.69 4.56 52.63 52.63 4.57
70
1500 21.10 19.41 3.12 27.66 25.42 3.48 34.80 31.73 3.86 43.06 38.25 4.30 52.27 47.56 4.78 61.55 61.55 5.15 64.28 64.28 5.26 65.82 65.82 5.32
1750 21.74 20.00 3.20 28.41 26.11 3.56 35.69 32.54 3.93 44.14 39.20 4.37 54.05 49.18 4.78 58.09 58.09 4.95 59.14 59.14 4.98 60.86 60.86 5.04
2000 22.28 20.49 3.29 28.99 26.64 3.63 36.41 33.19 4.01 44.99 39.96 4.45 53.54 48.72 4.78 54.89 54.89 4.82 55.75 55.75 4.84 57.14 57.14 4.88
2250 22.76 20.94 3.37 29.51 27.12 3.71 37.01 33.75 4.09 45.60 40.50 4.53 51.33 46.71 4.71 52.86 52.86 4.76 53.11 53.11 4.78 54.69 54.69 4.79
75
1500 19.86 18.27 3.13 26.45 24.30 3.50 33.42 30.47 3.90 41.56 36.91 4.34 50.73 46.16 4.84 60.74 60.74 5.28 64.72 64.72 5.46 66.38 66.38 5.53
1750 20.50 18.86 3.21 27.17 24.97 3.58 34.30 31.28 3.97 42.78 37.99 4.43 52.12 47.43 4.87 58.32 58.32 5.13 60.58 60.58 5.21 61.69 61.69 5.25
2000 21.01 19.33 3.30 27.78 25.53 3.66 35.05 31.95 4.04 43.56 38.69 4.50 53.28 48.48 4.92 55.85 55.85 5.02 56.61 56.61 5.03 58.53 58.53 5.10
2250 21.46 19.75 3.38 28.28 25.99 3.74 35.68 32.53 4.12 44.20 39.26 4.58 52.03 47.34 4.89 53.51 53.51 4.93 54.48 54.48 4.97 56.68 56.68 5.04
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 060 0.96 1.06 CK3BA 060 0.94 1.05
CC5A/CD5AB 060 0.96 1.06 CK5A/CK5BA 060 0.94 1.05
CC5A/CD5AW 060 0.98 1.04 CK5A/CK5BN 060 0.96 1.05
CE3AA 060 0.97 1.05 CK5A/CK5BT 060 0.94 1.05
CK3BA 060 0.96 1.06 CK5A/CK5BX 060 0.96 1.04
CK5A/CK5BA 060 0.96 1.05 COILS + 355MAV060100 VARIABLE SPEED FURNACE
CK5A/CK5BN 060 0.98 1.04 CC5A/CD5AA 060 0.96 1.11
CK5A/CK5BT 060 0.96 1.05 CC5A/CD5AB 060 0.96 1.11
CK5A/CK5BX 060 0.98 1.04 CC5A/CD5AW 060 0.99 1.11
FK4CNB 006 0.99 1.00 CE3AA 060 0.97 1.11
FV4ANB 006 1.00 1.00 CK3BA 060 0.96 1.12
COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE CK5A/CK5BA 060 0.96 1.11
CC5A/CD5AA 060 0.93 1.05 CK5A/CK5BN 060 0.98 1.10
CC5A/CD5AB 060 0.93 1.05 CK5A/CK5BT 060 0.96 1.11
CC5A/CD5AW 060 0.96 1.02 CK5A/CK5BX 060 0.98 1.11
CE3AA 060 0.95 1.03 COILS + 355MAV060120 VARIABLE SPEED FURNACE
CK3BA 060 0.94 1.04 CC5A/CD5AA 060 0.98 1.08
CK5A/CK5BA 060 0.94 1.04 CC5A/CD5AB 060 0.98 1.08
CK5A/CK5BN 060 0.96 1.04 CC5A/CD5AW 060 0.98 1.08
CK5A/CK5BT 060 0.94 1.04 CE3AA 060 0.97 1.08
CK5A/CK5BX 060 0.96 1.03 CK3BA 060 0.96 1.09
COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE CK5A/CK5BA 060 0.96 1.09
CC5A/CD5AA 060 0.96 1.05 CK5A/CK5BN 060 0.97 1.08
CC5A/CD5AB 060 0.96 1.05 CK5A/CK5BT 060 0.96 1.09
CC5A/CD5AW 060 0.96 1.04 CK5A/CK5BX 060 0.97 1.08
CE3AA 060 0.95 1.04 — — —
