—11—
* Ratings are net values reflecting the effects of circulating fan heat. Supplemental electric heat is not included. Ratings are based on:
Cooling Standard: 80°F (27°C) db 67°F (19°C) wb indoor entering air temperature and 95°F (35°C) db air entering outdoor unit.
High-Temp Heating Standard: 70°F (21°C) db indoor entering air temperature and 47°F (8°C) db 43°F (6°C) wb air entering outdoor unit.
Low-Temp Heating Standard: 70°F (21°C) db indoor entering air temperature and 17°F (–9°C) db 15°F (–10°C) wb air entering outdoor unit.
† Outdoor section/indoor section combination tested in accordance with DOE test procedure for heat pumps.
‡ Based on computer simulation. TXV must be Puron compatible and hard shutoff type.
** Indoor Airflow
COP — Coefficient of Performance
EER — Energy Efficiency Ratio
HSPF — Heating Seasonal Performance Factor
SEER — Seasonal Energy Efficiency Ratio
TC — Total Capacity (Btuh)
UNIT
SIZE
SERIES
INDOOR
UNIT
Cooling‡
Heating
HPSF
High-Temp Low-Temp
CFM** TC*
SEER EER
TC* Cop TC* Cop
High Low High Low High Low High Low High Low High Low
060-A
CC5A/CD5AW060 1838 1138 57,500 28,400 14.0 9.9 54,500 25,800 3.20 3.50 32,800 11,600 2.38 1.76 8.3
CE3AA060 1838 1138 58,000 28,600 14.0 10.0 54,000 26,000 3.14 3.52 32,600 11,500 2.38 1.76 8.2
CK3BA060 1838 1138 57,000 28,400 14.0 9.8 53,500 26,000 3.08 3.50 32,600 11,700 2.34 1.78 8.2
CK5A/CK5BA060 1838 1138 57,000 28,400 14.0 9.8 53,500 26,000 3.08 3.50 32,600 11,700 2.34 1.78 8.2
CK5A/CK5BN060 1838 1138 58,000 28,600 14.0 9.9 55,000 26,200 3.16 3.56 33,200 11,800 2.36 1.78 8.3
CK5A/CK5BT060 1838 1138 57,000 28,400 14.0 9.8 53,500 26,000 3.08 3.50 32,600 11,700 2.34 1.78 8.2
CK5A/CK5BX060 1838 1138 58,000 28,600 14.0 10.0 54,500 26,200 3.18 3.58 33,000 11,700 2.40 1.80 8.5
COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE
CC5A/CD5AA060 1838 1138 57,000 28,400 13.5 9.7 55,000 26,000 3.14 3.48 33,200 11,600 2.34 1.76 8.2
CC5A/CD5AB060 1838 1138 57,000 28,400 13.5 9.7 55,000 26,000 3.14 3.48 33,200 11,600 2.34 1.76 8.2
CC5A/CD5AW060 1838 1138 57,000 28,400 14.0 9.8 55,000 26,000 3.16 3.50 33,000 11,600 2.36 1.76 8.2
CE3AA060 1838 1138 58,000 28,600 14.0 9.8 54,000 26,000 3.12 3.50 33,000 11,500 2.36 1.76 8.2
CK3BA060 1838 1138 56,500 28,400 13.5 9.7 53,500 26,000 3.06 3.48 32,800 11,700 2.32 1.78 8.1
CK5A/CK5BA060 1838 1138 56,500 28,400 13.5 9.7 53,500 26,000 3.06 3.48 32,800 11,700 2.32 1.78 8.1
CK5A/CK5BN060 1838 1138 58,000 28,800 14.0 9.7 55,000 26,200 3.12 3.54 33,400 11,800 2.34 1.78 8.3
CK5A/CK5BT060 1838 1138 56,500 28,400 13.5 9.7 53,500 26,000 3.06 3.48 32,800 11,700 2.32 1.78 8.1
CK5A/CK5BX060 1838 1138 58,000 28,800 14.0 9.9 55,000 26,400 3.16 3.56 33,200 11,700 2.36 1.80 8.5
COILS + 355MAV060100 VARIABLE SPEED FURNACE
CC5A/CD5AA060 2000 1200 55,500 27,800 13.0 9.1 54,500 25,800 2.94 3.34 33,600 11,800 2.20 1.72 8.0
CC5A/CD5AB060 2000 1200 55,500 27,800 13.0 9.1 54,500 25,800 2.94 3.34 33,600 11,800 2.20 1.72 8.0
CC5A/CD5AW060 2000 1200 57,000 28,400 13.5 9.2 56,500 26,400 3.06 3.48 34,200 11,800 2.26 1.76 7.8
CE3AA060 2000 1200 58,000 28,600 13.5 9.3 55,500 26,400 3.00 3.48 34,200 11,800 2.24 1.76 7.8
CK3BA060 2000 1200 56,500 28,400 13.5 9.2 55,000 26,400 2.94 3.46 34,000 11,900 2.22 1.76 8.0
CK5A/CK5BA060 2000 1200 56,500 28,400 13.5 9.2 55,000 26,400 2.96 3.46 34,000 11,900 2.22 1.76 8.0
CK5A/CK5BN060 2000 1200 58,000 28,800 13.5 9.4 56,000 27,000 3.04 3.50 34,400 12,000 2.28 1.76 8.0
CK5A/CK5BT060 2000 1200 56,500 28,400 13.5 9.2 55,000 26,400 2.96 3.46 34,000 11,900 2.22 1.76 8.0
CK5A/CK5BX060 2000 1200 58,000 28,800 13.5 9.3 56,000 26,600 3.04 3.54 34,600 11,900 2.26 1.78 8.0
COILS + 355MAV060120 VARIABLE SPEED FURNACE
CC5A/CD5AA060 2000 1200 57,500 28,400 13.5 9.5 56,000 26,600 3.10 3.44 34,000 11,900 2.30 1.74 7.8
CC5A/CD5AB060 2000 1200 57,500 28,400 13.5 9.5 56,000 26,600 3.10 3.44 34,000 11,900 2.30 1.74 7.8
CC5A/CD5AW060 2000 1200 57,500 28,400 13.5 9.5 56,000 26,600 3.10 3.46 34,000 11,800 2.30 1.74 8.0
CE3AA060 2000 1200 58,000 28,600 13.5 9.6 55,500 26,400 3.06 3.48 33,800 11,800 2.30 1.74 7.8
CK3BA060 2000 1200 57,000 28,400 13.5 9.4 54,500 26,400 3.00 3.44 33,600 11,900 2.26 1.76 8.1
CK5A/CK5BA060 2000 1200 57,000 28,400 13.5 9.4 54,500 26,400 3.00 3.46 33,600 11,900 2.26 1.76 8.1
CK5A/CK5BN060 2000 1200 58,000 28,800 13.5 9.5 55,500 26,600 3.08 3.52 34,200 12,000 2.30 1.76 8.0
CK5A/CK5BT060 2000 1200 57,000 28,400 13.5 9.4 54,500 26,400 3.00 3.46 33,600 11,900 2.26 1.76 8.1
CK5A/CK5BX060 2000 1200 58,500 28,800 13.5 9.6 55,500 26,600 3.10 3.54 34,200 12,000 2.30 1.78 8.0
COMBINATION RATINGS Continued
