RECOMMENDED TUBE DIAMETERS
NOTE: Maximum long-line tube length of 50 ft liquid and vapor line sets indicated
above must be followed on all applications. Over 50 ft or 20 ft vertical differential,
refer to Application Guideline and Service Manual—Air Conditioners and Heat
Pumps Using Puron® Refrigerant.
UNIT
SIZE
TUBE LENGTH
(Ft)
LIQUID TUBE
DIAMETER (In.OD)
VAPOR TUBE
DIAMETER (In.OD)
024
0 to 50 3/8
5/8
036 3/4
048 7/8
060 1-1/8
