—24—
DETAILED COOLING CAPACITIES* continued
See notes on page 27.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW** Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
698BNX048000 Outdoor Section With FV4ANF005 Indoor Section - Low Speed
850
72 30.89 16.37 1.67 28.81 15.57 1.85 26.68 14.78 2.02 24.53 13.98 2.20 22.34 13.15 2.38 19.94 12.35 2.55
67 27.77 20.19 1.67 25.83 19.37 1.84 23.89 18.56 2.00 21.90 17.75 2.16 19.86 16.93 2.33 17.77 16.06 2.50
63†† 25.54 19.38 1.66 23.78 18.50 1.83 21.88 17.74 1.98 20.03 16.93 2.13 18.16 16.10 2.29 16.22 15.28 2.45
62 24.98 24.02 1.66 23.24 23.11 1.82 22.26 20.89 1.99 20.30 20.30 2.14 18.80 18.80 2.31 17.19 17.19 2.48
57 24.58 24.58 1.66 23.24 23.24 1.83 21.77 21.76 1.98 20.30 20.30 2.14 18.80 18.80 2.31 17.19 17.19 2.48
1075
72 32.10 18.03 1.69 29.87 17.21 1.88 27.59 16.38 2.06 25.26 15.55 2.23 22.87 14.73 2.41 20.40 13.87 2.59
67 28.89 22.83 1.69 26.76 21.88 1.87 24.70 21.13 2.04 22.59 20.28 2.20 20.45 19.41 2.37 18.38 18.25 2.54
63†† 26.58 21.86 1.69 24.61 21.00 1.85 22.66 20.15 2.02 20.69 19.30 2.17 18.74 18.41 2.34 16.93 16.93 2.50
62 26.61 26.61 1.69 25.04 25.04 1.86 23.45 23.45 2.03 21.82 21.82 2.19 20.12 20.12 2.36 18.34 18.34 2.54
57 26.61 26.61 1.69 25.04 25.04 1.86 23.45 23.45 2.03 21.82 21.82 2.19 20.11 20.11 2.36 18.33 18.33 2.54
1300
72 32.88 19.56 1.72 30.51 18.72 1.90 28.14 17.88 2.09 25.71 17.04 2.26 23.23 16.19 2.44 20.68 15.33 2.62
67 29.60 25.29 1.72 27.44 24.39 1.90 25.26 23.48 2.07 23.10 22.54 2.24 21.11 21.11 2.41 19.21 18.99 2.59
63†† 27.26 24.15 1.72 25.22 23.26 1.89 23.20 22.35 2.05 21.26 21.26 2.21 19.50 19.50 2.38 17.66 17.66 2.55
62 28.13 28.13 1.72 26.45 26.45 1.89 24.70 24.70 2.06 22.93 22.93 2.23 21.11 21.11 2.41 19.19 19.19 2.59
57 28.13 28.13 1.72 26.45 26.45 1.89 24.70 24.70 2.06 23.04 23.04 2.25 21.11 21.11 2.41 19.14 19.14 2.59
1525
72 33.39 21.00 1.75 30.96 20.12 1.93 28.50 19.28 2.11 26.03 18.42 2.29 23.47 17.57 2.47 20.83 16.68 2.65
67 30.13 27.53 1.75 27.91 26.59 1.92 25.74 25.53 2.10 23.80 23.80 2.27 21.82 21.82 2.45 19.85 19.48 2.64
63†† 27.78 26.23 1.75 25.72 25.23 1.92 23.82 23.82 2.08 22.01 22.01 2.25 20.15 20.15 2.42 18.23 18.22 2.60
62 29.33 29.33 1.75 27.52 27.52 1.92 25.68 25.68 2.10 23.80 23.80 2.27 21.82 21.82 2.45 19.75 19.75 2.63
57 29.34 29.34 1.75 27.52 27.52 1.92 25.68 25.68 2.10 23.80 23.80 2.27 21.83 21.83 2.45 19.76 19.76 2.63
1750
72 33.75 22.32 1.77 31.26 21.46 1.96 28.76 20.59 2.14 26.21 19.77 2.32 23.62 18.89 2.50 20.93 17.97 2.69
67 30.57 29.57 1.77 28.38 28.38 1.95 26.46 26.46 2.13 24.46 24.46 2.31 22.39 22.39 2.49 20.23 20.23 2.67
63†† 28.24 28.00 1.77 26.35 26.35 1.95 24.49 24.49 2.12 22.60 22.60 2.28 20.66 20.66 2.46 18.62 18.62 2.63
62 30.27 30.27 1.77 28.38 28.38 1.95 26.46 26.46 2.13 24.45 24.45 2.31 22.40 22.40 2.49 20.23 20.23 2.67
57 30.27 30.27 1.77 28.38 28.38 1.95 26.46 26.46 2.13 24.46 24.46 2.31 22.39 22.39 2.49 20.23 20.23 2.67
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Low Speed
Indoor
Section Size
Low Speed
Capacity Power Capacity Power
CC5A/CD5AA 060 0.99 1.11 CK5A/CK5BA 048 1.00 1.01
CC5A/CD5AB 060 0.99 1.11 060 1.00 1.01
CC5A/CD5AC 048 0.97 1.11 CK5A/CK5BN 048 1.00 1.01
CC5A/CD5AW 048 0.99 1.11 060 1.00 1.01
060 1.00 1.11 CK5A/CK5BT 048 1.00 1.01
CD5AA 048 0.99 1.11 060 1.00 1.01
CD5AB 048 0.99 1.11 CK5A/CK5BW 048 1.00 1.01
CE3AA 048 0.94 1.25 CK5A/CK5BX 060 1.00 1.01
060 1.00 1.11 COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE
CK3BA 048 1.00 1.11 CC5A/CD5AA 060 1.00 0.99
060 1.00 1.11 CC5A/CD5AB 060 1.00 0.99
CK5A/CK5BA 048 1.00 1.11 CC5A/CD5AC 048 1.00 0.99
060 1.00 1.11 CC5A/CD5AW 048 1.00 0.99
CK5A/CK5BN 048 1.00 1.11 060 1.00 0.99
060 1.00 1.11 CD5AA 048 1.00 0.99
CK5A/CK5BT 048 1.00 1.11 CD5AB 048 1.00 0.99
060 1.00 1.11 CE3AA 048 1.00 1.00
CK5A/CK5BW 048 1.00 1.11 060 1.00 0.99
CK5A/CK5BX 060 1.00 1.11 CK3BA 048 1.00 1.00
FV4ANB 006 1.00 1.00 060 1.00 0.99
FV4ANF 005 1.00 1.00 CK5A/CK5BA 048 1.00 1.00
FK4CNB 006 1.00 1.00 060 1.00 0.99
FK4CNF 005 1.00 1.00 CK5A/CK5BN 060 1.00 1.00
COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE CK5A/CK5BT 048 1.00 1.00
CC5A/CD5AA 060 1.00 1.01 060 1.00 0.99
CC5A/CD5AB 060 1.00 1.01 CK5A/CK5BW 048 1.00 0.99
CC5A/CD5AC 048 1.00 1.01 CK5A/CK5BX 060 1.00 1.00
CC5A/CD5AW 048 1.00 1.01 COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE
060 1.00 1.00 CC5A/CD5AA 060 1.00 1.00
CD5AA 048 1.00 1.01 CC5A/CD5AB 060 1.00 1.00
CD5AB 048 1.00 1.01 CC5A/CD5AC 048 1.00 1.00
CE3AA 048 1.00 1.01 CC5A/CD5AW 048 1.00 1.00
060 1.00 1.01 CC5A/CD5AW 060 1.00 1.00
CK3BA 048 1.00 1.01 CD5AA 048 1.00 1.00
060 1.00 1.01 CD5AB 048 1.00 1.00
