—20—
DETAILED COOLING CAPACITIES* continued
See notes on page 27.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW** Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
698BNX036000 Outdoor Section With FV4ANF003 Indoor Section - Low Speed continued
650
72 22.60 12.56 1.16 21.07 11.99 1.25 19.47 11.41 1.34 17.80 10.82 1.42 16.08 10.21 1.50 14.28 9.59 1.58
67 20.33 15.80 1.16 18.89 15.21 1.24 17.37 14.59 1.32 15.81 13.96 1.39 14.21 13.32 1.47 12.62 12.57 1.55
63†† 18.69 15.13 1.15 17.30 14.51 1.23 15.86 13.89 1.30 14.39 13.25 1.38 12.90 12.59 1.45 11.53 11.53 1.52
62 18.59 18.59 1.15 17.49 17.49 1.23 16.33 16.33 1.31 15.15 15.15 1.39 13.90 13.90 1.47 12.60 12.60 1.55
57 18.58 18.58 1.15 17.48 17.48 1.23 16.33 16.33 1.31 15.15 15.15 1.39 13.90 13.90 1.47 12.60 12.60 1.55
825
72 23.33 13.90 1.18 21.70 13.32 1.27 20.01 12.73 1.35 18.27 12.13 1.44 16.47 11.52 1.52 14.60 10.89 1.60
67 21.02 17.92 1.17 19.49 17.30 1.26 17.92 16.65 1.34 16.32 15.96 1.42 14.85 14.83 1.50 13.43 13.43 1.58
63†† 19.33 17.14 1.17 17.88 16.47 1.25 16.40 15.79 1.33 14.97 14.89 1.40 13.62 13.62 1.48 12.25 12.25 1.55
62 19.97 19.97 1.17 18.77 18.77 1.26 17.50 17.50 1.34 16.20 16.20 1.42 14.85 14.85 1.50 13.42 13.42 1.58
57 19.95 19.95 1.17 18.77 18.77 1.26 17.50 17.50 1.34 16.20 16.20 1.42 14.85 14.85 1.50 13.42 13.42 1.58
1000
72 23.77 15.08 1.19 22.09 14.51 1.28 20.35 13.92 1.37 18.56 13.32 1.45 16.71 12.70 1.54 14.83 12.08 1.62
67 21.48 19.86 1.19 19.93 19.16 1.28 18.37 18.37 1.36 16.98 16.98 1.44 15.53 15.53 1.52 14.01 14.01 1.61
63†† 19.78 18.89 1.18 18.33 18.13 1.27 16.98 16.98 1.35 15.62 15.62 1.42 14.22 14.22 1.50 12.85 12.54 1.58
62 20.99 20.99 1.19 19.70 19.70 1.27 18.36 18.36 1.36 16.98 16.98 1.44 15.53 15.53 1.52 14.01 14.01 1.61
57 20.98 20.98 1.19 19.69 19.69 1.27 18.37 18.37 1.36 16.98 16.98 1.44 15.53 15.53 1.52 14.01 14.01 1.61
1175
72 24.05 16.20 1.21 22.34 15.63 1.30 20.57 15.05 1.39 18.75 14.45 1.47 16.87 13.82 1.56 14.91 13.15 1.64
67 21.87 21.48 1.20 20.41 20.41 1.29 19.02 19.02 1.38 17.55 17.55 1.46 16.04 16.04 1.55 14.46 14.46 1.63
63†† 20.22 20.22 1.20 18.91 18.91 1.29 17.54 17.54 1.37 16.13 16.13 1.45 14.68 14.68 1.53 13.14 13.14 1.60
62 21.75 21.75 1.20 20.41 20.41 1.29 19.02 19.02 1.38 17.56 17.56 1.46 16.04 16.04 1.55 14.46 14.46 1.63
57 21.75 21.75 1.20 20.42 20.42 1.29 19.02 19.02 1.38 17.56 17.56 1.46 16.04 16.04 1.55 14.47 14.47 1.63
1350
72 24.25 17.26 1.22 22.52 16.67 1.32 20.72 16.13 1.41 18.88 15.52 1.49 16.97 14.87 1.57 15.01 14.14 1.66
67 22.41 22.16 1.22 20.98 20.98 1.31 19.51 19.51 1.40 18.01 18.01 1.48 16.44 16.44 1.57 14.80 14.80 1.65
63†† 20.76 20.76 1.22 19.39 19.39 1.30 17.98 17.98 1.39 16.53 16.53 1.47 15.01 15.01 1.55 13.42 13.42 1.63
62 22.37 22.37 1.22 20.98 20.98 1.31 19.51 19.51 1.40 18.01 18.01 1.48 16.44 16.44 1.57 14.80 14.80 1.65
57 22.36 22.36 1.22 20.98 20.98 1.31 19.51 19.51 1.40 18.01 18.01 1.48 16.44 16.44 1.57 14.82 14.82 1.65
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Low Speed
Indoor
Section Size
Low Speed
Capacity Power Capacity Power
CK5A/CK5BW 036 1.01 1.02 CD5AA 048 1.01 1.05
048 1.01 1.01 CD5AB 048 1.01 1.05
COILS + 355MAV042040 VARIABLE SPEED FURNACE CE3AA 036 1.00 1.07
CC5A/CD5AA 042 1.01 1.06 042 1.01 1.06
CC5A/CD5AB 042 1.01 1.06 048 1.01 1.06
CC5A/CD5AC 048 1.00 1.05 CK3BA 036 1.01 1.07
CC5A/CD5AW 036 1.01 1.06 042 1.01 1.06
042 1.01 1.05 048 1.02 1.06
048 1.01 1.05 CK5A/CK5BA 036 1.01 1.07
CD5AA 048 1.01 1.05 042 1.01 1.07
CD5AB 048 1.01 1.05 048 1.02 1.06
CE3AA 036 1.00 1.07 CK5A/CK5BE 042 1.02 1.06
042 1.02 1.06 CK5A/CK5BN 036 1.01 1.08
048 1.02 1.06 042 1.01 1.07
CK3BA 036 1.02 1.07 048 1.02 1.06
042 1.02 1.06 CK5A/CK5BT 036 1.01 1.07
048 1.02 1.05 042 1.01 1.07
CK5A/CK5BA 042 1.02 1.06 048 1.02 1.06
048 1.02 1.05 CK5A/CK5BW 036 1.01 1.07
CK5A/CK5BT 042 1.02 1.06 COILS + 355MAV042080 VARIABLE SPEED FURNACE
048 1.02 1.05 CC5A/CD5AA 036 1.01 1.04
CK5A/CK5BW 036 1.02 1.06 042 1.01 1.04
048 1.02 1.05 CC5A/CD5AB 036 1.01 1.04
COILS + 355MAV042060 VARIABLE SPEED FURNACE 042 1.01 1.04
CC5A/CD5AA 036 1.01 1.07 CC5A/CD5AC 048 1.01 1.04
042 1.01 1.06 CC5A/CD5AW 036 1.01 1.04
CC5A/CD5AB 036 1.01 1.07 042 1.01 1.04
042 1.01 1.06 048 1.01 1.04
CC5A/CD5AC 048 1.00 1.06 CD5AA 048 1.01 1.04
CC5A/CD5AW 036 1.01 1.06 CD5AB 048 1.01 1.04
