FontMatrices for 6dots/mmPrinthead
Font
Matrix
(in dots)
Type*
CharacterSize
Inches
Millimeters
H
ei
ght
W
idt
h
In
te
r-
ch
ar
act
er
ga
p
H
ei
ght
W
idt
h
C
h
ar
./
in
ch
H
ei
ght
W
idt
h
Ch
ar
./
m
m
A
9
5
1
U-L-D
0.059
0.039
25.40
1.50
1.00
1.00
B
11
7
2
U
0.072
0.059
16.93
1.83
1.50
0.67
C, D
18
10
2
U-L-D
0.118
0.079
12.70
3.00
2.00
0.50
E
21
10
3
OCR-B
0.138
0.085
11.72
3.50
2.17
0.46
F
26
13
3
U-L-D
0.171
0.105
9.53
4.33
2.67
0.38
G
60
40
8
U-L-D
0.394
0.315
3.18
10.00
8.00
0.13
H
17
11
4
OCR-A
0.112
0.098
10.16
2.83
2.50
0.40
GS
24
24
0
SYMBOL 0.157
0.157
6.35
4.00
4.00
0.25
Ø
Default: 15 X 12
U-L-D
Scalable
* U = Uppercase, L = Lowercase, D = Descenders
Standard Printer Font Examples
Figure 1.1 Default Fonts (8 Dots/mm Printhead)
