General Description
Top view & bottom view
Tape cutter button
USB port
(for PT-7600 only)
Keyboard
AC adapter connector
Display
Back cover
Release lever
Print head
Tape exit slot
Tape cassette compartment
Battery compartment
Top view
Bottom view
