BOXLIGHT Matinee 1HD - Manual (Page 2)

2
Table of Contents
Table of Contents 2
Part Names and Functions 9
Video Input 24
Computer Input
/ (RGB Scart 21-Pin Video Input)
31
Setting 42
Appendix 44
To the Owner 3
Feature and Design 8
Front 9
Bottom 10
Back 10
Terminal 11
Top Controls and Indicators 12
Remote Control 13
Remote Control Batteries Installation 14
Operating Range 14
Input Source Selection (Direct Operation) 24
Input Source Selection (Menu Operation) 25
Video System Selection (Video/S-Video) 26
Video System Selection (Y-Pb/Cb-Pr/Cr) 26
Image Level Selection (Direct Operation) 27
Image Level Selection (Menu Operation) 27
Image Level Adjustment 28
Screen Size Adjustment (Direct Operation) 30
Screen Size Adjustment (Menu Operation) 30
Input Source Selection (Direct Operation) 31
Input Source Selection (Menu Operation) 31
Computer System Selection 32
Compatible Computer System 33
Computer Adjustment (Auto) (Direct Operation) 34
Computer Adjustment (Auto) (Menu Operation) 34
Computer Adjustment (Manual) 35
Image Level Selection (Direct Operation) 38
Image Level Selection (Menu Operation) 38
Image Level Adjustment 39
Screen Size Adjustment (Direct Operation) 41
Screen Size Adjustment (Menu Operation) 41
Setting 42
Lamp Replacement 44
Lamp Replace Counter 45
Warning Temp. Indicator 46
Air Filter Care and Cleaning 46
Cleaning the Projection Lens 46
Troubleshooting 47
Indicators and Projector Condition 48
Technical Specifications 49
Dimensions 50
Configuration of Terminals 51
Optional Parts 51
Installation 15
Positioning the Projector 15
Tilting the Projector 15
Moving the Lens 16
Connecting to Video Equipment 17
Connecting to a Computer 18
TRADEMARKS
● Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple Computer,Inc.
● IBM, VGA, XGA, and PS/2 are trademarks or registered trademarks of International Business Machines, Inc.
● Windows and PowerPoint are registered trademarks of Microsoft Corporation.
● Each name of corporations or products in the owner's manual is a trademark or a registered trademark of its
respective corporation.
Safety Instructions 4
Compliance 6
Basic Operation 19
Turning On the Projector 19
Turning Off the Projector 19
Focus Adjustment 20
Zoom Adjustment 20
Keystone Adjustment 21
No Show Function 21
On-Screen Menu 22
Contents of Menus 23
