10
Part Names and Functions
Bottom
Back
CAUTION
Hot air is exhausted from the exhaust vents. When using or installing the projector, the following
precautions should be taken.
● Do not put any flammable objects near these vents.
● Keep front grills at least 3’(1m) away from any objects, especially heat-sensitive objects.
● Do not touch this area (including the top cabinet), especially screws and metallic parts. This area will
become hot while the projector is used.
This projector detects internal temperature and will automatically adjust the speed of the Cooling
Fans.
EXHAUST VENTS
POWER CORD CONNECTOR TERMINALS
AND CONNECTORS
LAMP COVER
ADJUSTABLE FEET
AND
FEET LOCK LATCHES
AIR INTAKE VENTS
AND AIR FILTERS
MAIN ON/OFF
SWITCH
AIR INTAKE VENTS
CAUTION
Do not put any objects at
the bottom that could
obstruct air circulation.
See the caution
below.
