12
WARNING
TEMP.
LAMP
REPLACE
READY
LAMP
MENU INPUT
ON-OFF
SELECT
Part Names and Functions
Used to open or close
the on-screen menu.
(p22)
MENU BUTTON
READY INDICATOR
SELECT BUTTON
POWER ON–OFF BUTTON
INPUT BUTTON
WARNING TEMP. INDICATOR LAMP INDICATOR
POINT BUTTONS
LAMP REPLACE INDICATOR
Lights green when the
projector is ready to be
turned on. It flashes
green in Power
management mode.
(p43) Becomes dim when the
projector is turned on.
And it is bright when
the projector is in
stand-by mode. Turns yellow when the
life of the projection
lamp draws to an end.
(p44) Flashes red when internal
projector temperature is
too high. (p46)
Used to select input
source. (p24, 31)
Used to select an item or adjust
value in the on-screen menu. They
are also used to pan the image in
Digital zoom mode. (p41) Used to execute the item
selected. It is also used
to expand the image in
Digital zoom mode.
(p41)
Used to turn the projector
on or off. (p19)
Top Controls and Indicators
