Page 18: Terminals of the projector
18
Installation
ON
1
DIP
ON
OFF
2 3 4 5 6
13" MODE (640 x 480)
16" MODE (832 x 624)
19" MODE (1024 x 768)
OFF
ON
ON
ON
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
1
2
3
4
5
6
OFF
OFF
ON
ON
ON
ON
21" MODE (1152 x 870)
IBM-compatible computer or Macintosh computer (VGA / SVGA / XGA / SXGA)
VGA Cable
✽
Monitor Output
Desktop type
Laptop type
COMPUTER IN
Cables used for connection
NOTE :
When connecting the cable, the power
cords of both the projector and the external
equipment should be disconnected from
AC outlet. Turn the projector and
peripheral equipment on before the
computer is switched on.
MAC Adapter
✽
Set slide switches
according to the
chart.
• VGA Cable (HDB 15 pin)
✽
• MAC Adapter (When connecting to Macintosh computer)
✽
✽
option
Terminals
of the Projector
Set switches as shown in the table
below depending on RESOLUTION
MODE that you want to use before
you turn on projector and computer.
◆ MAC ADAPTER (Not supplied)
Connecting to a Computer
