BOXLIGHT Matinee 1HD User Manual

Page 11

Text mode
Original mode

Part Names and Functions

Connect the S-VIDEO
output from video
equipment to this
jack. (Refer to page
17.)

S-VIDEO INPUT JACK

Connect the computer
output to this jack.
(Refer to page 18.)

COMPUTER INPUT

TERMINAL

SERVICE PORT JACK

This jack is used to service
the projector.

Connect the composite
video output from video
equipment to VIDEO jack.
(Refer to page 17.)

VIDEO INPUT JACK

(VIDEO)

Connect the component video
outputs to Y, Pb/Cb, and Pr/Cr
jacks.
(Refer to page 17.)

COMPONENT VIDEO INPUT JACK

(

Y-Pb/Cb-Pr/Cr

)

Terminal

This projector uses a micro processor to control this unit, and occasionally, this micro processor may malfunction and need to
be reset. This can be done by pressing the RESET button with a pen, which will shut down and restart the unit. Do not use
the RESET function excessively.
