3
BRYANT ACCESSORIES
MECHANICAL
OR ELECTRONIC
AIR CLEANER
Cleans the air of smoke, dirt, and
many pollens commonly found.
Saves decorating and cleaning
expenses by keeping carpets,
furniture, and drapes cleaner.
Electronic air cleaner is shown.
A97432
CONTROLS:
THERMOSTATS
AND ZONING
Available in programmable and
non-programmable models,
Bryant thermostats maintain a
constant, comfortable tempera-
ture level in the home.
For the ultimate in home comfort,
Bryant’s 2, 4, and 8-zone systems
allow temperature control of indi-
vidual “zones” of the home. This is
accomplished through a series of
electronic dampers and
remote room sensors. The
4-zone system is shown.
A01484
MODEL HUMCCLFP
HUMIDIFIER
By adding moisture to winter-dry
air, a Bryant humidifier can often
improve comfort and keep
furniture, rugs, and draperies in
better condition. Moisturizing
household air also helps to retain
normal body heat and provides
comfort at lower temperatures.
C04009
A08153
ACCESSORIES
ELECTRONIC AIR CLEANER
(EAC)
Model EACB
AIR PURIFIER Models GAPAAXBB1625, GAPAAXBB2025
MECHANICAL AIR CLEANER Models EZXCAB, FILCAB
HUMIDIFIER Model HUM
HEAT RECOVERY
VENTILATOR
Model HRV
ENERGY RECOVERY
VENTILATOR
Model ERV
UV LIGHTS Model UVL
THERMOSTAT ---
NON---PROGRAMMABLE
For use with 1---speed Air Conditioner --- deg. F/C, Auto Changeover --- T6---NAC, T2---NAC
For use with 1---speed Heat Pump --- deg. F/C, Auto Changeover --- T6---NHP, T2---NHP*
For use with 2---speed Air Conditioner --- deg. F/C, Auto Changeover --- T6---NRH*
For use with multi---use / stage configurations --- deg. F/C, Auto Changeover/Temperature and
Humidity Control --- T6---PRH
{
THERMOSTAT ---
PROGRAMMABLE
For use with 1---speed Air Conditioner --- deg. F/C, Auto Changeover, 7---Day Programmable ---
T6---PAC
For use with 1---speed Heat Pump --- deg. F/C, Auto Changeover, 7---Day Programmable ---
T6---PHP*
For use with 2---speed Air Conditioner --- deg. F/C, Auto Changeover, 7---Day Programmable ---
T6---PRH*
For use with 1---speed Air Conditioner --- deg. F/C, 5---2 Day Programmable --- T6---PAC
For use with multi---stage applications --- deg. F/C, Auto Changeover, 7---Day Programmable ---
T2---PHP
}
For multi---use / stage configurations --- deg. F/C, Auto Changeover, 7---Day Programmable/
Temperature and Humidity Control ---T6---PRH
{
ZONING CONTROL
Zone Perfect 3---Zone kit --- ZONEBB3ZAC01, ZONEBB3ZHP01
2---Zone Perfect Plus kit/Temperature and Humidity Control --- ZONEBB2KIT01---B
4---Zone Perfect Plus kit/Temperature and Humidity Control --- ZONEBB4KIT01---B
8---Zone Perfect Plus kit/Temperature and Humidity Control --- ZONEBB8KIT01---B
*Model HP and 2S thermostat must be field converted to air conditioner operation.
{
Thermidistatt Control can be configured for multiple use and staging. It must be configured for each specific application.
} Dual Fuel thermostat is used with furnace and heat pump application.
