Table 10 — Fan Performance Data, 542J150 Units
LEGEND
NOTES:
1. Boldface indicates field-supplied drive required.
2.
indicates field-supplied motor and drive required.
3. Factory-shipped motor drive range is 862 to 1132 rpm. Other rpms
may require a field-supplied drive.
4. Maximum continuous bhp is 4.25 maximum continuous watts are
3775. Do not adjust motor rpm such that motor maximum bhp and/
or watts is exceeded at the maximum operating cfm.
5. Static pressure losses (i.e., EconoMi$erIV) must be added to
external static pressure before entering Fan Performance table.
6. Interpolation is permissible. Do not extrapolate.
7. Fan performance is based on wet coils, clean filters, and casing
losses. See Table 12 for accessory/FIOP static pressure information.
8. Extensive motor and drive testing on these units ensures that the
full horsepower and watts range of the motor can be utilized with
confidence. Using fan motors up to the watts or bhp rating shown
will not result in nuisance tripping or premature motor failure. Unit
warranty will not be affected.
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Watts Bhp Rpm Watts Bhp Rpm Watts Bhp Rpm Watts Bhp Rpm Watts Bhp
3750 724 481 0.55 838 685 0.78 937 889 1.01 1028 1097 1.25 1111 1309 1.49
4000 754 613 0.70 865 824 0.94 962 1034 1.18 1050 1247 1.42 1131 1463 1.67
4250 786 757 0.86 893 975 1.11 987 1191 1.36 1073 1408 1.60 1152 1629 1.86
4500 818 914 1.04 922 1138 1.30 1013 1360 1.55 1097 1583 1.80 1174 1808 2.06
4750 850 1084 1.23 951 1313 1.50 1040 1541 1.76 1122 1770 2.02 1197 2000 2.28
5000 883 1267 1.44 980 1501 1.71 1068 1736 1.98 1147 1969 2.24 1221 2204 2.51
5250 917 1464 1.67 1011 1703 1.94 1096 1943 2.21 1174 2183 2.49 1246 2423 2.76
5500 950 1675 1.91 1041 1918 2.19 1124 2165 2.47 1201 2409 2.75 1272 2655 3.02
5750 985 1901 2.17 1072 2147 2.45 1153 2400 2.73 1228 2650 3.02 1298 2901 3.31
6000 1020 2142 2.44 1103 2391 2.72 1183 2649 3.02 1256 2905 3.31 1324 3160 3.60
6250 1055 2398 2.73 1135 2650 3.02 1213 2912 3.32 1284 3175 3.62 1352 3435 3.91
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Watts Bhp Rpm Watts Bhp Rpm Watts Bhp Rpm Watts Bhp Rpm Watts Bhp
3750 1190 1526 1.74 1265 1746 1.99 1337 1972 2.25 1405 2199 2.51 1471 2431 2.77
4000 1208 1684 1.92 1281 1908 2.17 1351 2136 2.43 1418 2368 2.70 1483 2603 2.97
4250 1227 1853 2.11 1299 2082 2.37 1367 2313 2.64 1433 2548 2.90 1496 2787 3.18
4500 1247 2036 2.32 1317 2268 2.58 1384 2503 2.85 1448 2742 3.12 1510 2983 3.40
4750 1269 2232 2.54 1337 2468 2.81 1403 2707 3.08 1465 2948 3.36 1526 3194 3.64
5000 1291 2441 2.78 1358 2680 3.05 1422 2923 3.33 1484 3168 3.61 1544 3418 3.89
5250 1315 2664 3.03 1380 2907 3.31 1443 3154 3.59 1503 3403 3.88 1562 3655 4.16
5500 1339 2900 3.30 1403 3148 3.59 1464 3398 3.87 1524 3651 4.16 — — —
5750 1364 3151 3.59 1426 3403 3.88 1486 3657 4.17 1545 3914 4.46 — — —
6000 1389 3416 3.89 1450 3672 4.18 1510 3930 4.48 — — — — — —
6250 1415 3695 4.21 1476 3957 4.51 1534 4219 4.81 — — — — — —
Bhp — Brake Horsepower Input to Fan
FIOP — Factory-Installed Option
Watts — Input Watts to Motor
