Control panel setup
8 - 9
8
WIRELESS
■
SecureEasySetup
You can configure the wireless network settings using SecureEasySetup
TM
to configure your printer in a wireless network on page 3-4.
■
COMM.MODE
This field shows the current network communication mode; AD-HOC or INFRASTRUCTURE.
■
LIST SSID
This field shows a list of available names for the wireless networks (SSID) within range. You can select
the SSID from the list. See SSID on page 3-1.
■
SSID
You can enter the SSID name for the wireless network you want to connect with (uses a maximum of 32
digits and characters 0-9, a-z and A-Z in ASCII values). See SSID on page 3-1.
■
CHANNEL
This field shows the currently used channel in an Ad-hoc mode. See Channels on page 3-2.
■
AUTHENTICATION
You can select an authentication mode; OPEN SYSTEM, SHARED KEY, WPA-PSK or LEAP. You can select
SHARED KEY
, WPA-PSK or LEAP when INFRASTRUCTURE is selected in COMM.MODE. See Authentication
■
ENCRYPTION
You can select an encryption type; NONE, WEP, TKIP, AES or CKIP. See Encryption methods on page 3-3.
■
WEP KEY SELECT
You can select a WEP key; KEY1, KEY2, KEY3 or KEY4. See Network key on page 3-3.
■
WEP KEY1 (2, 3 or 4) SIZE
You can select an either size of WEP KEY1 (2, 3 or 4); 64(40)BITS or 128(104)BITS. See Network
key on page 3-3.
■
WEP KEY1 (2, 3 or 4) TYPE
You can select a format of WEP KEY1 (2, 3 or 4); ASCII or HEX (hexadecimal). See Network key on page
3-3.
■
WEP KEY1 (2, 3 or 4)
You can enter a new WEP key for each WEP KEY number; 1, 2, 3 or 4. See Network key on page 3-3.
■
PASSPHARASE
If you have selected WPA-PSK for an authentication mode, you will need to enter a network key that is
more than 7 and less than 64 characters in length.
■
USER
If you have selected LEAP for an authentication mode, you will need to enter a user ID that is 64 characters
or less in length.
