2 Phone setup
• CONNECTORS
1 Connector for battery charger.
2 Connector for headsets, data cable and
other accessories.
3 Connector for microphone.
• INSTALL SIM CARD AND BATTERY
Keep all SIM cards out of the reach of small children. For availability and information on
using SIM card services, contact your SIM card vendor. This may be the service provider or
another vendor.
The SIM card and its contacts can be easily damaged by scratches or bending, so be careful
when handling, inserting, or removing the card.
Before installing the SIM card, always make sure that the phone is switched off and
disconnected from the charger or any enhancement; then remove the battery.
• With the back of the phone facing
you, push the back cover release
button (1) and, at the same time,
lift the back cover off the phone (2)
• Slide the battery into the back
cover (3) until you hear it click
into place.
Important: Insert the battery
exactly as shown in the diagram. The contacts on the battery must be aligned with
the contacts on the phone for the phone to operate.
