Adjusting 3-band parametric
equalizer

For

Custom1 and Custom2 equalizer curves,

you can adjust the front, rear and center
equalizer curves separately by selecting a cen-
ter frequency, an equalizer level and a Q factor
for each band.

! A separate Custom1 curve can be created

for each source.

! A Custom2 curve can be created common

to all sources.

! The center speaker largely determines the

sound image and getting the balance right
isn

’t easy. We recommend reproducing a 2-

ch. audio (a CD for example) and getting
the balance right among the speakers ex-
cept for the center, and then reproducing a
5.1-ch. audio (Dolby Digital or DTS) and ad-
justing the center speaker output to the
balance you have already got among the
other speakers.

% Touch PARAMETRIC EQ on the DSP
function menu.

Note

You can select a center frequency for each band.
You can change the center frequency in 1/3-oc-
tave steps, but you cannot select frequencies that
have intervals shorter than 1 octave among the
center frequencies of the three bands.

Speaker select

Touch c or d to select SP-SEL.

Each time you touch c or d selects the item
in the following order:
SP-SEL (speakers)

—BAND (bands)—

FREQUENCY (center frequency)

—LEVEL

(equalizer level)

—Q. FACTOR (Q factor)

Touch c or d to select the speaker to

be adjusted.
Touch c or d until the desired speaker ap-
pears in the display.
REAR (rear speakers)

—CENTER (center speak-

er)

—FRONT (front speakers)

# You cannot select speakers whose size is set
at

OFF. (Refer to Setting the speaker setting on

page 79.)

Band

Touch c or d to select BAND.

Each time you touch c or d selects the item
in the following order:
SP-SEL (speakers)

—BAND (bands)—

FREQUENCY (center frequency)

—LEVEL

(equalizer level)

—Q. FACTOR (Q factor)

Touch c or d to select the equalizer

band to be adjusted.
Each time you touch c or d selects equalizer
bands in the following order:
LOW (low)

—MID (mid)—HIGH (high)

Frequency

Touch c or d to select FREQUENCY.

Each time you touch c or d selects the item
in the following order:
SP-SEL (speakers)

—BAND (bands)—

FREQUENCY (center frequency)

—LEVEL

(equalizer level)

—Q. FACTOR (Q factor)

Touch c or d to select the center fre-

quency of selected band.
Touch c or d until the desired frequency ap-
pears in the display.
40Hz

—50Hz—63Hz—80Hz—100Hz—125Hz

—160Hz—200Hz—250Hz—315Hz—400Hz—
500Hz

—630Hz—800Hz—1kHz—1.25kHz—

1.6kHz

—2kHz—2.5kHz—3.15kHz—4kHz—

5kHz

—6.3kHz—8kHz—10kHz—12.5kHz
