Controlling the rest of your system (In case of SC-LX83) 10
88
En
Pairing the RF adapter and remote control
Pairing is necessary in order to use the RF
communications function. Perform the operation below
after connecting the RF adapter and receiver.
1 Switch on the receiver.
2 Set the RF Remote Setup on this receiver’s Other
Setup menu to ON.
For details, see RF Remote Setup (SC-LX83 only) on
page 116.
3 Press the SETTING button on the front of the RF
adapter.
RF adapter’s LED blinks red.
4 While pressing MULTI OPERATION, press VIDEO
PARAMETER on the remote control.
The remote display shows
PAIRING.
5 Press ENTER on the remote control.
AUTHORIZATION flashes and pairing is performed.
When pairing is successful,
SUCCESS is displayed and
pairing is completed. RF adapter’s LED lights green.
If ERROR is displayed, pairing has not been successful.
Check the connections and distance with the RF adapter,
then start over from step 1.
The remote control unit’s receiver operation mode must
be set to “RF” in order to operate the receiver with RF two-
way communications. Make this setting as described at
Operating this receiver by RF communications below.
Operating this receiver by RF
communications
Use this procedure to make the remote control settings
to operate the receiver using RF two-way
communications. The settings can be made individually
for the main zone, ZONE 2 and ZONE 3. Connect the
receiver and RF adapter and pair the RF adapter and
remote control unit beforehand.
1 While pressing MULTI OPERATION, press HOME
MENU.
The remote display shows
SETUP MENU.
2 Use
/ to select ‘IR/RF SELECT’, then press
ENTER.
Check that the units are paired. If
RECEIVER MAIN is
displayed, pairing has been performed properly, so
proceed to step 3. If
RF MODE ONLY flashes, pairing has
not been performed properly, so perform this procedure
again after performing pairing (see Pairing the RF adapter
and remote control on page 88).
3 Use
/ to select the receiver zone for which you
want to use RF two-way communications, then press
ENTER.
4 Use
/ to select ‘RF MODE’, then press ENTER. 1
Select IR MODE to return to operation by infrared signal.
5 If you want to operate other zones with RF two-
way communications, repeat steps 3 and 4.
Operating other components by RF
communications
Up to 4 other components connected to the receiver can
be operated by RF communications. Use the IR blaster to
communicate between the RF adapter and other
components, and switch the remote control’s setting to
RF. The remote control’s setting can be switched
individually for each input.
Note
1 When RECEIVER is selected and RF MODE is set at step 3, HMG NET RADIO, ADAPTER, iPod USB and TUNER are automatically set to the
RF mode. Note that RF MODE cannot be set for OPTION 1 and OPTION 2.
To mount on a shelf above the
component
Double-faced
tape
Rack
Remote control sensor
To mount on the component
Remote control sensor
Double-
faced tape
