The other setup menu, Volume setup, Remote control mode setup – Pioneer SC-LX73 User Manual
Page 115: The system setup and other setup menus 12
The System Setup and Other Setup menus
12
115
En
The Other Setup menu
The
Other Setup menu is where you can make
customized settings to reflect how you are using the
receiver.
1
Set the remote control to the receiver operation
mode, then press HOME MENU.
A Graphical User Interface (GUI) screen appears on your
TV. Use
/// and ENTER to navigate through the
screens and select menu items. Press
RETURN to
confirm and exit the current menu.
2
Select ‘System Setup’ from the Home Menu.
3
Select ‘Other Setup’, then press ENTER.
4
Select the setting you want to adjust.
If you are doing this for the first time, you may want to
adjust these settings in order:
•
HDMI Setup – Synchronizes this receiver with your
Pioneer component supporting
Control with HDMI
(page 69).
•
Volume Setup – Sets up the volume-related
operations of this receiver (see below).
•
Remote Control Mode Setup – Sets this receiver’s
remote control mode (see below).
•
Flicker Reduction – Adjusts the way the GUI screen
looks (page 116).
•
RF Remote Setup (SC-LX83 only) – Allows the CU-
RF100 to be used even when the receiver is in the
standby mode (page 116).
•
EXTENSION Setup (SC-LX73 only) – Allows the CU-
RF100 to be used even when the receiver is in the
standby mode (page 116).
•
Multi Ch In Setup – Specifies the optional settings for
a multi-channel input (page 116).
•
Pairing Bluetooth Setup – Use to pair a Bluetooth
ADAPTER and Bluetooth wireless technology device
(page 55).
5
Make the adjustments necessary for each setting,
pressing RETURN to confirm after each screen.
Volume Setup
You can set the maximum volume of this receiver or
specify what the volume level will be when the power is
turned on.
1
Select ‘Volume Setup’ from the Other Setup menu.
2
Select the Power ON Level setting you want.
The volume can be set so that it is always set to the same
level when the receiver’s power is turned on.
•
LAST (default) – When the power is turned on, the
volume is set to the same level as when the power
was last turned off.
• “
---” – When the power is turned on, the volume is set
to minimum level.
•
–80.0dB to +12.0dB – Specify the volume to be set
when the power is turned on, in steps of 0.5 dB.
It is not possible to set a volume level greater than the
value specified at Volume Limit setup (see below).
3
Select the Volume Limit setting you want.
Use this function to limit the maximum volume. The
volume cannot be increased above the level set here,
even by operating
MASTER VOLUME button (or the dial
on the front panel).
•
OFF (default) – The maximum volume is not limited.
•
–20.0dB/–10.0dB/0.0dB – The maximum volume is
limited to the value set here.
4
Select the Mute Level setting you want.
This sets how much the volume is to be turned down
when
MUTE is pressed.
•
FULL (default) – No sound.
•
–40.0dB/–20.0dB – The volume will be turned down
to the level specified here.
5
When you’re finished, press RETURN.
You will return to the
Other Setup menu.
Remote Control Mode Setup
• Default setting:
1
This sets this receiver’s remote control mode to prevent
erroneous operation when multiple units of the receiver
are being used.
1
Select ‘Remote Control Mode Setup’ from the
Other Setup menu.
2
Select the Remote Control Mode setting you want.
3
Select “OK” to change the remote control mode.
4
Follow the instructions on the screen to change the
remote control’s setting.
See Operating multiple receivers on page 80 (SC-LX83)/
page 92 (SC-LX73).
5
When you’re finished, press RETURN.
You will return to the
Other Setup menu.
