7
Chapter
7
47
Home Menu
Using the Home Menu
The following section shows you how to make detailed
settings to specify how you’re using the receiver, and also
explains how to fine-tune individual speaker system settings
to your liking.
Important
• The OSD will not appear if you have connected using the
composite output to your TV. Use HDMI connection for
Home Menu.
• If headphones are connected to the receiver, disconnect
them.
• You can’t use the Home Menu when the NETRADIO,
M.SERVER
, FAVORITE, iPod/USB or ADAPTER input is
selected.
1
Switch on the receiver and your TV.
Press
 RECEIVER to switch on.
2
Switch the TV input to the input that connects this
receiver to the TV through the corresponding HDMI
cable.
3
Press , then press HOME MENU .
The Home Menu appears on your TV. Use /// and
ENTER on the remote control to navigate through the
screens and select menu items. Press RETURN to exit
the current menu.
• Press HOME MENU at any time to exit the Home
Menu.
4
Select the setting you want to adjust.
• Auto MCACC – This is a quick and effective automatic
surround setup (see Automatically setting up for surround
sound (MCACC) on page 23 ).
• Manual SP Setup
- Speaker Setting – Specify the size and number of
speakers you’ve connected (see below).
- X.Over – Specify which frequencies will be sent to the
subwoofer ( page 48 ).
- Channel Level – Adjust the overall balance of your
speaker system ( page 49 ).
- Speaker Distance – Specify the distance of your
speakers from the listening position ( page 49 ).
• Input Assign
- Analog Input – Specify what you’ve connected to the
ANALOG IN1 audio input ( page 50 ).
- Component Input (VSX-827 only) – Specify what you’ve
connected to the component video inputs ( page 50 ).
• Speaker System (VSX-827 only) – Specifies how you are
using the speaker terminals ( page 50 ).
• Video Parameter (VSX-827 only)
- Video Converter – Converts video signals for output
from the HDMI OUT terminal for all video types ( page 50 ).
- Resolution – Specifies the output resolution of the video
signal ( page 51 ).
- Aspect – Specifies the aspect ratio ( page 51 ).
• Pre Out Setting (VSX-527 only) – Specify how to use the
PRE OUT SURR BACK/FRONT HEIGHT outputs (see The
Pre Out Setting (VSX-527 only) on page 51 ).
• HDMI Setup – Set the audio return channel function (see
HDMI Setup on page 53 ).
• Auto Power Down – Sets to automatically turn off the
power when the receiver has not operated for several hours
(see The Auto Power Down menu on page 52 ).
• Network Standby – Allows the AirPlay function to be used
even when the receiver is in the standby mode (see The
Network Standby menu on page 52 ).
• FL Demo Mode – Sets the demo display on the front panel
display (see The FL Demo Mode menu on page 52 ).
Manual speaker setup
This receiver allows you to make detailed settings to optimize
the surround sound performance. You only need to make
these settings once (unless you change the placement of your
current speaker system or add new speakers).
These settings are designed to fine-tune your system, but if
you’re satisfied with the settings made in Automatically
setting up for surround sound (MCACC) on page 23 , it isn’t
necessary to make all of these settings.
Important
• VSX-827 only: Depending on the Speaker System setting,
there will be differences in the speaker items that can be
adjusted. The OSD display for these operating instructions
is an example of when the Speaker System setting is set to
Surr. Back
.
• VSX-527 only: Depending on the Pre Out Setting, there will
be differences in the speaker items that can be adjusted.
The OSD display for these operating instructions is an
example of when the Pre Out Setting is set to Surr. Back.
Speaker Setting
Use this setting to specify your speaker configuration (size,
number of speakers). It is a good idea to make sure that the
settings made in Automatically setting up for surround sound
(MCACC) on page 23 are correct.
RECEIVER
H o m e M e nu
1 . Au t o M C AC C
2 . M a nu a l S P S e t u p
3 . I n p u t A s s i g n
4 . S p e a k e r S y s t e m
5 . V i d e o Pa r a m e t e r
6 . H D M I S e t u p
7 . Au t o Pow e r D ow n
8 . N e t wo r k S t a n d by
9 . F L D e m o M o d e
H o m e M e nu
1 . Au t o M C AC C
2 . M a nu a l S P S e t u p
3 . I n p u t A s s i g n
4 . P r e O u t S e t t i n g
5 . H D M I S e t u p
6 . Au t o Pow e r D ow n
7 . N e t wo r k S t a n d by
8 . F L D e m o M o d e
VSX-827 VSX-527
