12
EN
Attaching a lens to the camera
2
1
1
2
3
4
3
2
1
Body cap
Lens cap
Alignment mark (Red)
Lens release button
1
Remove the body cap from the camera and
the rear cap from the lens
2
Attach a lens to the camera
• Make sure the ON/OFF switch is set
to OFF.
• Do not press the lens release button.
3
Remove the lens cap (3, 4)
Removing the lens from the
camera
While pressing the lens release button
(1), rotate the lens in the direction of the
arrow (2).
• Align the lens attachment mark (red) on
the camera with the alignment mark (red)
on the lens, then insert the lens into the
camera’s body (1).
• Rotate the lens in the direction indicated
by the arrow until you hear it click (2).
Rear cap
Lens attachment mark
(Red)
1
2
