12
EN
Attaching a lens to the camera
Rear cap
Body cap
Lens cap
Lens attachment mark (Red) Alignment mark (Red)
Lens release button
1
Remove the body cap from the camera
and the rear cap from the lens
2
Attach a lens to the camera
• Make sure the power switch is
set to OFF.
• Do not press the lens release
button.
3
Remove the lens cap
(3, 4)
Removing the lens from the
camera
While pressing the lens release button
(1), rotate the lens in the direction of
the arrow (2).
• Align the lens attachment mark (red)
on the camera with the alignment
mark (red) on the lens, then insert the
lens into the camera’s body (1).
• Rotate the lens in the direction
indicated by the arrow until you hear it
click (2).
