Olympus EVOLT E-410 - Manual (Page 5)

EN
5
Basic guide
1
Remove the body cap from the camera and the rear cap from the lens
2
Attaching a lens to the camera
• Align the lens attachment mark (red) on the camera
with the alignment mark (red) on the lens, then
insert the lens into the camera’s body (1). Rotate
the lens in the direction indicated by the arrow until
you hear it click (2).
• Do not press the lens release button.
3
Remove the lens cap
Removing the lens from the camera
While pressing the lens release button (1), rotate the lens in the
direction as indicated by (2).
Attaching a lens to the camera
1
2
1
2
Rear cap
Body cap
1
2
Lens cap
Alignment mark
(Red)
Lens attachment mark (Red)
2
1
Lens release button
