40
E
NAMES AND FUNCTIONS OF PARTS
Main Unit
1 Shutter release/OK button ..................................P. 72
2 Flash mode button ..............................................P. 88
3 Erase mode button ............................................P. 122
4 LCD control panel................................................P. 44
5 Selftimer/Protect mode button ....................P. 98/120
6 Resolution selection/Index-Display button
........................................................................P. 86/114
7 Function button ..........................................P. 100/116
8 Card compartment cover ....................................P. 54
9 Flash .....................................................................P. 88
0 Lens barrier..........................................................P. 56
! Lens
@ Selftimer signal....................................................P. 98
# Connector cover
$ Video output connector (NTSC) .......................P. 126
% Computer connector (RS-232C) ................P. 128/144
^ AC adapter connector .........................................P. 50
PREPARATION
1 2 3 4 5 6 7
9 0 !
$ ^ % 8
@ #
