Images and actual product may vary slightly.
Subject to change for the purpose of technical
advances. Accessories not included.
Immediately after unpacking check all parts for
damage and verify all parts are present!
Do not use the backup camera system if
damaged, incorrect on-screen display or if the
instructions for use are missing!
1 LCD - Monitor 3.5" (8.9 cm)
1 Monitor arm with suction cup base
1 Monitor cable with 12 V plug
1 Camera with connector cable
2 Camera mounting brackets
1 Radio transmitter
1 Connector cable for transmitter
4 Cable ties
2 Clamped cable connections
2 Thread screws
2 Locking nuts
1 Plastic ring
1 Instructions for use
3.1 Contents
3.0 PRODUCT
DESCRIPTION
2.2.17 Run the cables so as not to cause tripping
hazards and the cables cannot be damaged by
e.g. objects with sharp edges! Do not run cables
across hot surfaces!
2.2.16 Do not wear metal body jewelry when
installing the backup camera system. Doing so
could result in a short circuit and burns!
2.2.15 When removing dirt or ice and snow from
the camera lens be extremely careful so as not to
scratch it.
2.2.14 If you are unsure how to install the back-
up camera system consult a qualified specialist or
have the system installed by a qualified specialist.
2.2.13 Even if the fuse inside the 12 V plug is
tripped, backup camera system‘s camera and
wireless transmitter will remain ready for use.
2.2.12 Improper installation of the backup came-
ra system may damage the vehicle‘s electrical
equipment. This could result in an accident or fire.
Caution! Risk of property damage and
personal injury!
2.2.11 Be sure the ignition and all vehicle
loads are powered off before starting with
installation of the backup camera system!
2.2.10 If operation system malfunctions and
damage to the backup camera system occurs
during operation, immediately disconnect the
equipment from the 12 V vehicle power supply!
2.2.9 When installing the backup camera system
always be sure the safety and functionality of
other systems and equipment in the vehicle is not
impaired! Please follow the instructions of the
automaker‘s manual.
2.2.8 Risk of short circuits! Verify the correct
polarity when connecting the camera cable to the
vehicle power. Refer to the manual for notices
and the automaker‘s wiring diagram.
2.2.7 During installation be sure cables are se-
curely and tightly mounted. Do not mount these
to conductive materials. If cables are run through
walls with sharp edges (metal sheets, etc.) use
ductwork or conduit to prevent cable damage.
Protect cables from damage, do not bend.
Immediately replace damaged cables!
GB 19
