Atlantis Land A02-RA241-W54 - Manual (Page 73)

WIRELESS ROUTER ADSL2+
67
3.6.3.7 Advanced
Configuration options within the Advanced section are for users who wish to take advantage
of the more advanced features of the router. Users who do not understand the features
should not attempt to reconfigure their router, unless advised to do so by support staff.
• Static Route
• Dynamic DNS
• VLAN Control
• Device Management
• IGMP
3.6.3.7.1 Static Routed
Click on the Static Routing and then choose Create IP V4Route to get the below figure to
add a routing table.
• Destination: Enter the destination subnet IP.
• Gateway: Enter the gateway IP address which the packet is forwarded to.
• Netmask: Subnet mask of destination IP addresses based on above destination
subnet IP.
• Cost: This is the same meaning as Hop. Usually, leave it as 1.
• Interface: Enter the interface, which the packet is forwarded to.
