Atlantis Land A02-RA241-W54 - Manual (Page 61)

WIRELESS ROUTER ADSL2+
55
: Before using these buttons to edit or delete a policy, please select one policy
you want to edit/delete from the radio option .
: After you have configured the policies, you can press this button to apply the
configuration. If you want to make the change persistent in flash, choose
in the left windows to save it into flash.
When you press or buttons described above, the following page will show up in
your browser. You can use it to define a QOS policy.
Controlled Traffic Flow: Specify the traffic flow you want to control. For GRE protocol,
there is no need to specify the IP addresses or Application ports in this page. For other
protocols, at least one value shall be given.
Packet type: The packet type will be controlled. For GRE protocol, there is no need to
specify the IP addresses or Application ports in this page. For other protocols, at least one
value shall be given.
ANY: No specified protocol type is specified.
TCP
UDP
ICMP
