- 3 -

2-2

Wiring method

Wire the inside stations in a station-to-station (daisy-chained) manner.

3

MOUNTING

2-3

Cable

1. Use 2-conductor, non-shielded cable. Vinyl-jacketed cable with

PE(polyethylene) insulated wires is recommended.

2. Never use loose wires, shielded wire, twisted pairs, or coaxial cable.
3. When using existing cable with multiple wires, terminate both ends of

each unused pair with a 120 ohm resistor.

2-4

Wiring distance

1.0mm

100m
100m
100m

10m

100m

A
A'
B
C
D

18AWG

330'
330'
330'

33'

330'

0.65mm

50m
50m
50m

5m

50m

22AWG

165'
165'
165'

16'

245'

100m

E

330'

50m

165'

Mounting

[1] Screw (x4)
[2] Mounting bracket
[3] Two-gang box

• Provide a box DEEP enough to accommodate all cables incl. options.

[4] DIN rail
1. Depress UNLOCK button (to unlock or to insert the wire securely).
2. Insert the cable into terminal.
3. When GANG BOX is not provided, the cable can be surface run from

the top or bottom of the unit. Cut open the cable inlet hole to run
wires to the back of the unit.

JA-2MECD

JA-2MCD

JA-2MECD

JA-2MCD

JA-2MECD

JA-2MCD

JA-2SD

JA-DAC

2

2

4

4

B1, B2

B1, B2

B1, B2

B1, B2

4

4

JA-DAC

JA-DAC

2

B1, B2

JA-2HCD

JA-2SD

JA-2HCD

JA-2SD

JA-2HCD

JA-2SD

JA-2HCD

8

4

4

JA-DAC

2

B1, B2

JA-2SD

JA-2HCD

JA-2SD

JA-2HCD

JA-DAC

JA-D

JA-2HCD

B1
B2

A1
A2

B1
B2

+
-

+
-

B1
B2

A1
A2

(x2)

A1
A2
A1
A2

120

120

JA-2MECD

JA-2MCD

JA-2MECD

JA-2MCD

JA-2HCD

JA-2HCD

PS

JA-DAC

JA-DAC

JA-D

PS-2420

PS-2410

D1

D2

M

S1

S2

A

A'

B

C

E

D

IER-2

JA-2SD

JA-2SD

ADAP

CAM

JAW-AZ

: motion detect sensor or sensor / camera

CAM

JA-2MECD

JA-2MCD

JA-2HCD

PS-2420

PS-2420S

PS-2420UL

PS-2420DIN
PS-2410DIN

83.5mm
(3-5/16")

46mm

(1-13/16")

[3]

[2]

[1]

[4]

83.5mm
(3-5/16")

[3]

[2]

1

2

9mm

(3/8")

3.
