Precautions 2
2-3
Space Requirements
Scanner:
There should be a clearance of the following dimensions between the wall
and the rear of the unit as well as it's right and left sides to provide ample
space for the ventilation ports to dissipate heat.
System Printer (MSP 3000):
For ease of operation, maintenance and replenishment of supplies, the
minimum clearance diagrammed below is required. Install the unit in an
area that allows easy access.
150mm or
5-7/8" 150mm or
5-7/8" 150mm or
5-7/8"
150mm
5-7/8" 150mm
5-7/8" 150mm
5-7/8"
