Operation
15 F232090 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Display Interpretations
UWP_01
Program identification code (ROM).
This is an example only.
DONE End of cycle
DOOR Door not locked problem
EMTY Empty problem
FILL Fill problem
SDLY Spin coast delay
NEXT
Select cycle or open door or select
program
NCYC Cycle not available
STOP Stop button pressed or cycle ended
A1 Auxiliary output #1
A2 Auxiliary output #2
A3 Signal
CF Cold flush
CH Cold fill to high level
CM Cold fill to medium level
CL Cold fill to low level
CO Cold fill to overflow
CR Cold rinse
CY Cycle number
D1 Drain #1
D2
Drain #2 (This feature is operational on
UWPV models only.)
F Heat select temperature in ° Fahrenheit
C Heat select temperature in ° Centigrade
HF Hot flush
HH Hot fill to high level
HM Hot fill to medium level
HL Hot fill to low level
HO Hot fill to overflow
HR Hot rinse
HS High speed spin
MS Medium speed spin
HT Heat (steam or electric)
--M
Minutes (used when programming
time)
--S
Seconds (used when programming
time)
SK Soak
S1 Supply #1 (Detergent)
S2 Supply #2 (Bleach)
S3 Supply #3 (Sour)
S4 Supply #4 (Softener)
S5 Supply #5 (Specialty)
TH
Controlled temperature fill to high
level
TM
Controlled temperature fill to medium
level
TL Controlled temperature fill to low level
TO Controlled temperature overflow
W1 Wash #1 (normal reversing)
W2 Wash #2 (gentle reversing)
W3 Wash #3 (no agitation)
W4
Wash #4 (distribution speed–forward
only)
W5 Wash #5 (temp.-controlled cool-down)
WF Warm flush
WH Warm fill to high level
WM Warm fill to medium level
WL Warm fill to low level
Display Interpretations (Continued)
