Lenovo ThinkPad X230 Tablet - Manual (Page 96)

• “1070 Palm rest” on page 70
• “1080 Backup battery” on page 72
• “1090 PCI Express Mini Card for wireless LAN/WiMAX” on page 73
• “1100 PCI Express Mini Card for wireless WAN or mSATA solid-state drive” on page 76
• “1110 Bluetooth daughter card” on page 79
• “1120 Keyboard bezel” on page 80
• “1130 LCD unit” on page 83
• “1140 DC-in connector, Tablet Digitizer Pen case and switch assembly, and base cover” on page 86
Removal steps of ExpressCard slot assembly
1
1
Step Screw (quantity) Color Torque
1 M2 × 3.5 mm, wafer-head, nylon-coated (2) Silver 0.181 Nm
(1.85 kgf-cm)
3
2
90 Hardware Maintenance Manual
