Remove the screw 4 , and then remove the media card reader slot board 5 6 .
4
5
Step Screw (quantity) Color Torque
4 M2 × 3 mm, flat-head, nylon-coated (1) Black 0.181 Nm
(1.85 kgf-cm)
0
6
7
1140 Thermal module assembly
For access, remove this FRU:
“1020 Base cover” on page 43
Removal steps of the thermal module assembly
Remove the cables that aligned on the thermal module assembly.
1
1
1
2
2
Chapter 8 . Removing or replacing a FRU 57
