Attention:
• Do not drop the drive or apply any physical shock to it. The drive is sensitive to physical shock. Improper
handling can cause damage and permanent loss of data.
• Before removing the drive, have the user make a backup copy of all the information on it if possible.
• Never remove the drive while the computer is operating or in suspend mode.
Removal steps of the M.2 solid-state drive
Remove the screw 1 .
1
Step Screw (quantity) Color Torque
1 M2 × 4 mm, flat-head, nylon-coated (1) Black 0.181 Nm
(1.85 kgf-cm)
Remove the M.2 solid-state drive.
2
1080 Hard disk drive assembly
For access, remove this FRU:
“1020 Base cover” on page 43
48 Hardware Maintenance Manual
