Remove the hard disk drive bracket 2 .
2
1090 Fingerprint board bracket and fingerprint board
For access, remove this FRU:
“1020 Base cover” on page 43
Removal steps of the fingerprint board bracket and fingerprint board
Remove the screw 1 , and then remove the fingerprint board bracket 2 .
2
1
Step Screw (quantity) Color Torque
1 M2 × 2.5 mm, flat-head, nylon-coated (1) Black 0.181 Nm
(1.85 kgf-cm)
Chapter 8 . Removing or replacing a FRU 51
