Removal steps of the speaker assembly
Detach the connector 1 and then remove the screws and 2 .
2
2
1
Step Screw (quantity) Color Torque
2 M2.5 × 2.5 mm, flat-head, nylon-coated (2) Black 0.392 Nm
(4.0 kgf-cm)
Remove the speaker assembly 3 .
3
3
1110 Touch panel
For access, remove these FRUs in order:
•
“1020 Base cover” on page 43
• “1030 Battery pack” on page 44
Chapter 8 . Removing or replacing a FRU 53
