Figure 29. Removing a fan assembly
4. Touch the static-protective package that contains the new fan assembly to any unpainted surface on the
outside of the storage array. Then, remove the new fan assembly from the package.
5. Note the orientation of the new fan assembly and slide it into the chassis until it snaps into position.
Then, tighten the screws 1 to secure the fan assembly to the chassis.
Figure 30. Installing a fan assembly
6. If you are instructed to return the old fan assembly, follow all packaging instructions and use any
packaging materials that are supplied to you for shipping.
Chapter 6 . Installing, removing, or replacing hardware 43
