Owner’s Manual #513666 Rev.1 2 M202B Model Machines
1.2 SPECIFICATIONS
M202B A/C M202B A/C Remote M202B W/C
Dimensions Machine with crate Machine with crate Machine with crate
width
27-1/2’’
(69,9 cm)
48’’
(121,9 cm)
27-1/2’’
(69,9 cm)
42-1/2’’
(108,0 cm)
27-1/2’’
(69,9 cm)
42-1/2’’
(108,0 cm)
height
59’’
(149,9 cm)
69-1/4’’
(175,9 cm)
57-1/2’’
(146,1 cm)
67’’
(170,2 cm)
57-1/2’’
(146,1 cm)
67’’
(170,2 cm)
depth
40-3/8’’
(102,6 cm)
60’’
(152,4 cm)
32’’
(81,3 cm)
48’’
(121,9 cm)
32’’
(81,3 cm)
48’’
(121,9 cm)
Weight
845 lbs
(383,2 kg)
1100 lbs
(498,9 kg)
645 lbs
(292,5 kg)
945 lbs
(428,6 kg)
845 lbs
(383,2 kg)
1100 lbs
(498,9 kg)
Electrical 1 PH 3 PH 1 PH 3 PH 1 PH 3 PH
circuit ampacity
(per barrel)
20A 15A 15A 15A 20A 15A
overcurrent protection
device (per barrel)
25A 15A 15A 15A 25A 15A
Drive Motor Two - 2 hp
Cooling
Self contained air cooled units
require 6” (15,2 cm) air space
on sides and 24” (60,9 cm) at
the back. They are charged
with R-404A.
Air cooled units require one
remote condensing unit
(with compressor) per barrel.
Condensing units #285090
and #285091 ship from the
factory with 20 lbs of R-404A
for up to a 50’ line set. Add
1 lb of refrigerant for every
10’ increase to the line set.
Line set max 100’. (Remote
condensers CU-0050 and CU-
0060 do not ship charged and
require 20 lbs of R-404A)
Water cooled units are self
contained and require a
Standard Hose Adapter water
fi tting and a 1/2” OD drain
fi tting for each barrel. They are
charged with R-404A.
Hopper Volume Two - 5.4 gallon (20,57 liters)
Remote Condensing Unit (1 per barrel)
Dimensions Condenser
width 37-3/4’’ (95,9 cm)
height 17-1/4’’ (43,7 cm)
depth 28-1/4’’ (71,7 cm)
Weight 222 lbs (100,7 kg)
Electrical 1 Phase, 208-230 VAC, 60Hz 3 Phase, 208-230 VAC, 60Hz
circuit ampacity 20A minimum 15A minimum
overcurrent protection
device
25A maximum 20A maximum
Refrigerant R-404A
Charge 20 lbs. (Charged at Factory)
Refrigerated Line
Sizes
Liquid Line - 3/8”
Suction Line - 5/8”
