Owner’s Manual #513684 30 SU444I2 Model Machines
6.2 LEFT SIDE SOFT SERVE AUGER SHAFT AND FRONT DOOR PARTS
Part Number Description Quantity
149003 Bushing - Front Auger Support 1
381804 Auger Flight 6
482004 Knob (Air Bleed Valve & Blender Motor) 7
624520 O-Ring - Air Bleed Valve - Black 1
624598 O-Ring - Spigot - Black 2
624678 O-Ring - Rear Seal - Black 1
625133 O-Ring - Front Door - Black 1
667868 Seal - Rear Auger (Orange) 1
694200 Spring - Air Bleed Valve 1
694255 Spring - Auger Flight 6
2104552 Support - Front Auger 1
2183106 Valve - Air Bleed 1
2187680 Spigot Body 1
2187696 Front Door 1
2187880 Adapter - Rear Seal (Two O-Ring Style) 1
4151178 Auger Shaft 1
694200
2187680
2187696
624520
625133
2183106
149003
694255
381804
4151178
482004
2104552
624598
2187880
667868
624678
Install O-Ring
Into Groove
