Solo

Solo Single Channel

Single Channel

Single Channel Specifications

Specifications

Dimensions, (L, W, H) and Weight
Single Channel Charger Base

3.9” (10 cm) x 2.4” (6 cm) x 1.0” (2.56 cm), 0.5 lb (0.23 kg)

Wearable Microphone:

0.9” (2.3 cm) x 0.8” (2.0 cm) x 2.6” (6.6 cm), 0.05 lb (0.02 kg)

TableTop Microphone:

1.5” (3.8 cm) x 0.8” (2.0 cm) x 3.3” (8.4 cm), 0.05 lb (0.02 kg)

XLR Adapter:

0.9” (2.3 cm) x 0.8” (2.0 cm) x 4.0” (10.2 cm), 0.05 lb (0.02 kg)

Shipping Weight

1.5 lbs (0.68 kg)

Radio Frequency

02-DSKSYS - 1.92 to 1.93 GHz (UPCS North America)
04-DSKSYSEU - 1.88 to 1.90 GHz (DECT EU)

Connectors
Single Channel Charger Base

Power – 5VDC, proprietary 0.7mm connector
Mini USB – 5 pin connector, USB 2.0

Audio unbalanced In/Out – 2.5mm

Tip: Audio Out (line level, 0dBV)
Ring: Audio In (line level, 0dBV)
Shield: GND

Wireless Microphone

Power – proprietary 4 pin connector
Audio – 2.5mm mono audio

Microphone patterns Executive unidirectional – cardioid.
TableTop omni-directional and uni-directional available.
Power Requirements

Power Adapter

110 - 240VAC, 50-60Hz to 5VDC, 300mA

Battery

Lithium Polymer, up to 8 hours talk time

Charge Time

2.0 hours approx.

Range

65’ (20 meters) approx. (no obstructions)

Audio Bandwidth

100-7000 Hz

Encryption

128-bit DSAA (DECT Standard
Authentication Algorithm) authentication,
64 bit DECT Standard Cipher

Environmental Requirements
Temperature

40° to 105° F (5° to 40° C) operating

Humidity

20% to 85%

R e v o l a b s S o l o ™ S i n g l e C h a n n e l

0 2 - D S K M A N - P A P - 1 1

D e c e m b e r 2 0 0 7 ( R e v 3 . 1 )

Note:

Microphones must be fully charged

and paired to the Charger Base
prior to first use.
