Pneufit – Norgren PUSH-IN Fittings User Manual
Page 24

N/en 9.1.020.24
Pneufit
®
C
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. © 2014 Norgren Ltd
2006-9005e
3/14
In-line non-return valve (in), taper thread
C01G2
In-line non-return valve (in), ISO G thread
C02G2
In-line non-return valve (out), taper thread
C01G3
In-line non-return valve (out), ISO G thread
C02G3
Ø A
B
C
G
Model
4
M5
31,5
3,5
10
C02G20405
4
G1/8
27,5
6
10
C02G20418
6
G1/8
32,5
6
12
C02G20618
8
G1/4
37
7
15
C02G20828
10
G3/8
54
8
22
C02G21038
12
G1/2
60,5
9
24
C02G21248
Ø A
B
C
G
Model
4
M5
31,5
3,5
10
C02G30405
4
G1/8
27,5
6
10
C02G30418
6
G1/8
32,5
6
12
C02G30618
8
G1/4
37
7
15
C02G30828
10
G3/8
54
8
22
C02G31038
12
G1/2
60,5
9
24
C02G31248
Ø A
B
C
G
Model
4
R1/8
27,5
8
10
C01G20418
6
R1/8
32,5
8
12
C01G20618
8
R1/4
37,5
10
14
C01G20828
Ø A
B
C
G
Weight (g) Model
4
R1/8
27,5
8
10
11
C01G30418
6
R1/8
32,5
8
12
16
C01G30618
8
R1/4
37,5
10
14
24
C01G30828
C
ø
A
IN
G
B
C
ø
A
OUT
G
B
G
C
IN
B
ø
A
G
C
OUT
B
ø
A
Ø A
C
Model
4
42
C00GL0400
6
47,5
C00GL0600
8
55,5
C00GL0800
Ø A
C
Model
10
65
C00GL1000
12
73
C00GL1200
C
øA
C
øA
In-line non-return valve (PBT)
C00GL
In-line non-return valve (Aluminium)
C00GL
