82400/82410
N/en 5.8.301.04
03/14
2014-5769c
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. © 2014 Buschjost GmbH
Dimensions
G1/4 ... 2
1/4 ... 2 NPT
Port size R
A
B
H
H1
L
L1
T
Typ
G1/4
44
19,5
78,5
67
60
27,5
12
8240000.9101.xxxxx
1/4 NPT
44
19,5
78,5
67
60
27,5
10
8241000.9101.xxxxx
G3/8
44
19,5
78,5
67
60
27,5
12
8240100.9101.xxxxx
3/8 NPT
44
19,5
78,5
67
60
27,5
10,5
8241100.9101.xxxxx
G1/2
44
19,5
81
67
67
31
14
8240200.9101.xxxxx
1/2 NPT
44
19,5
81
67
67
31
13,5
8241200.9101.xxxxx
G3/4
50
24
88
71,5
80
36,5
16
8240300.9101.xxxxx
3/4 NPT
50
24
88
71,5
80
36,5
14
8241300.9101.xxxxx
G1
62
29,5
97,5
77
95
44
18
8240400.9101.xxxxx
1 NPT
62
29,5
97,5
77
95
44
17
8241400.9101.xxxxx
G 1 1/4
92
44,5
124,5
95,5
132
60
20
8240500.9101.xxxxx
1 1/4 NPT
92
44,5
124,5
95,5
132
60
17
8241500.9101.xxxxx
G1 1/2
92
44,5
124,5
95,5
132
60
22
8240600.9101.xxxxx
1 1/2 NPT
92
44,5
124,5
95,5
132
60
17
8241600.9101.xxxxx
G2
109
54,5
142,5
108
160
74
24
8240700.9101.xxxxx
2 NPT
109
54,5
142,5
108
160
74
17,5
8241700.9101.xxxxx
1
Solenoid rotatable 360°
2
Socket turnable 4 x 90°
(Socket included)
Note to Pressure Equipment Directive (PED):
The valves of this series, including the connection size DN 25
(G 1), are according to Art. 3 § 3 of the Pressure Equipment Directive (PED)
97/23/EG. This means interpretation and production are in accordance to
engineers practice wellknown in the member countries.
The CE-sign at the valve refers not to the PED. Thus the declaration of
conformity is not longer applicable for this directive.
For valves
> DN 25 (G 1) Art. 3 § (1) No.1.4 applies.
The basic requirements of the Enclosure I of the PED must be fulfilled.
The CE-sign at the valve includes the PED. A certificate of conformity of
this directive will be available on request.
Note to Electromagnetic Compatibility Guideline (EEC):
The valves shall be provided with an electrical circuit which ensures the
limits of the harmonised standards EN 61000-6-3 and EN 61000-6-1 are
observed, and hence the requirements of the Electromagnetic
Compatibility Guideline (2004/108/EG) satisfield.
33
R
T
L1
B
L
H1
H
20
30
ø A
42
26,5
48,3
36
50
1
2
P
A
