82400/82410
824˙˙˙˙.˙˙˙˙.˙˙˙˙˙
N/en 5.8.301.02 03/14
2014-5769c
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. © 2014 Buschjost GmbH
Thread form Substitute
ISO G 0
NPT 1
Port size Substitute
1/4 0
3/8 1
1/2 2
3/4 3
1 4
1 1/4 5
1 1/2 6
2 7
Valve options Substitute
Normally open (NO),
from G1 1/4 with solenoid 9151
0,1 ... 16 bar
01
Manual override 02
Seat seal FPM,
Fluid temperature –5 ... +110°C
03
Seat seal EPDM,
for hot water,
max. fluid temperature +110°C
0,3 ... 16 bar (up to G1)
0,3 ... 10 bar (from G1 1/4)
14
Latching system
impuls time min. 30 ms
only for d.c. 6 V, 12 V and 24 V
50
Frequency Substitute
See table frequency codes xx
Voltage Substitute
See Voltage codes xxx
Solenoid options Substitute
G1/4 ... 1
Operating pressure
0,1 ... 16 bar
9101
G1 1/4 ... 2
Operating pressure
0,1 ... 10 bar
9101
G1 1/4 ... 2
Operating pressure
0,1 ... 16 bar
9151
Further versions on request!
Standard solenoid systems
Design DIN VDE 0580
Voltage range ±10%
Duty cycle 100% ED
Protection class EN 60529 IP65
Socket Form A acc. to DIN EN 175301-803 (included)
According to DIN VDE 0580 at a solenoid temperature of +20°C.
At operating state temperature the input power of a coil decreases by up to
ca. 30% due to physical reasons.
Electrical details for all solenoid systems
Voltage and Frequency Solenoid 9101 *1)
Code
Voltage
Code
Frequency
Voltage Frequency Power consumption
Inrush
Holding
024 00 24 V d.c. - 8 W 8 W
024 50 24 V a.c. 50 Hz 15 VA 12 VA
110 50 110 V a.c. 50 Hz 15 VA 12 VA
120 60 120 V a.c. 60 Hz 15 VA 12 VA
230 50 230 V a.c. 50 Hz 15 VA 12 VA
Voltage and Frequency Solenoid 9151 *1)
024 00 24 V d.c. - 18 W 18 W
024 50 24 V a.c. 50 Hz 45 VA 35 VA
110 50 110 V a.c. 50 Hz 45 VA 35 VA
120 60 120 V a.c. 60 Hz 45 VA 35 VA
230 50 230 V a.c. 50 Hz 45 VA 35 VA
ATEX category Protection class Solenoid Standard voltages
II2GD EEx m II T4 T 130°C
with 3 m connection cable
9136 24 V d.c., 110 V a.c., 230 V a.c.
Attention!
The conditions imposed on the Ex approvals lead to reduction of the permissible
standard temperature ranges in the cases of explosion protected solenoids.
Additional solenoid systems
*1)
r
coil only
Option selector
x
