V60 Series
Littleton, CO USA Phone: 303-794-2611 www.norgren.com VAL-3-7
5/2 Solenoid Pilot Valves
14 4 2 12
5 1 3
Symbol Model Port
size Pilot
exhaust Pilot
supply Solenoid
variant Flow Cv
(l/min) Operating
pressure (bar) Pilot pressure
(bar) Dimensional
drawing no. lbs
(kg)
1 (+) 12 (Solenoid 2)
2 (–) 12 + 14
3 (+) 14 (Solenoid 1)
1 2
3
Double solenoid DIN EN 175 301-803 (DIN 43650 type C) 4 pin
Coil & voltage codes
Secondary
24 V d.c. 13 A 2 W
VVoollttaaggee Coil code Power inrush/hold
S Syym mbbooll Plug no. Function Actuation
12 V d.c. 12J 2 W 54469-01
24 V d.c. 13J 2 W 54469-02
24 V 50/60 Hz 14J 4/2.5 VA 54469-04
48 V 50/60 Hz 16J 4/2.5 VA 54469-07
110/120 V 50/60 Hz 18J 4/2.5 VA 54469-03
220/240 V 50/60 Hz 19J 6/5 VA 54469-08
VVoollttaaggee Coil code Power inrush/hold Model
Voltage tolerance: ±10%
Rating: 100% E.D.
Protection class: IP 65 with sealed plugs (ISO 6952)
Electrical details
Plug configuration, valve side/twin pilot
Primary (22 mm coil industrial standard)
3-Pin Industrial Standard 22mm
A = no connector
B = Cable grip 0-240Vac/Vdc
54934-01
C = 6 ft molded cable, 0-240Vac/Vdc 54934-21
H = Cable grip w/indicator light 24Vdc 54934-08
J = Cable grip w/indicator light 120Vac 54934-02
Z = 1/2" Conduit 0-240Vac/Vdc 54934-05
5 = 6 ft molded cable w/indicator light, surge suppression, 24Vac/Vdc 54934-30
6 = 6 ft molded cable w/indicator light, 120Vac 54934-35
4-Pin Connector
A = no connector
Y = 4–pin cable grip 0-240Vac/Vdc
0588666
X = 4–pin 10’ molded cable 0-240Vac/Vdc 0102144
Connectors
**** Insert coil connector code from tables below.
For manual override options, substitute ‘x’ as follows:
1 = without manual override
2 = locking
3 = non-locking
V60P517A-Ax**** 1/8 Internal Not collected Primary 0.75 (750) 29 to 116 (2 to 8) – 0.53 (0.24) 9
V60P527A-Ax**** 1/8 External Not collected Primary 0.75 (750) 26" Hg to 116 (-0.9 to 8) 44 to 116 (3 to 8) 0.53 (0.24) 9
V60P517D-Cx13AA 1/8 Internal Collected Secondary 0.75 (750) 29 to 145 (2 to 10) – 0.51 (0.23) 11
V60P5223-Cx13AA 1/8 External Collected Secondary 0.75 (750) 26" Hg to 145 (-0.9 to 10) 44 to 145 (3 to 10) 0.51 (0.23) 11
V61R517A-Ax**** 1/4 Internal Not collected Primary 1.30 (1300) 29 to 116 (2 to 8) – 0.73 (0.33) 9
V61R527A-Ax**** 1/4 External Not collected Primary 1.30 (1300) 26" Hg to 116 (-0.9 to 8) 44 to 116 (3 to 8) 0.73 (0.33) 9
V61R517D-Cx13AA 1/4 Internal Collected Secondary 1.30 (1300) 29 to 145 (2 to 10) – 0.71 (0.32) 11
V62S517A-Ax**** 3/8 Internal Not collected Primary 2.60 (2600) 29 to 116 (2 to 8) – 1.36 (0.62) 9
V62S527A-Ax**** 3/8 External Not collected Primary 2.60 (2600) 26" Hg to 116 (-0.9 to 8) 44 to 116 (3 to 8) 1.36 (0.62) 9
V62S517D-Cx13AA 3/8 Internal Collected Secondary 2.60 (2600) 29 to 145 (2 to 10) – 1.34 (0.61) 11
V62S527D-Cx13AA 3/8 External Collected Secondary 2.60 (2600) 26" Hg to 145 (-0.9 to 10) 44 to 145 (3 to 10) 1.34 (0.61) 11
V60P511A-Ax**** 1/8 Internal Not collected Primary 0.75 (750) 29 to 116 (2 to 8) – 0.73 (0.33) 10
V60P522A-Ax**** 1/8 External Not collected Primary 0.75 (750) 26" Hg to 116 (-0.9 to 8) 44 to 116 (3 to 8) 0.51 (0.23) 11
V60P522D-Cx13AA 1/8 External Collected Secondary 0.75 (750) 26" Hg to 145 (-0.9 to 10) 44 to 145 (3 to 10) 0.51 (0.23) 11
V61R511A-Ax**** 1/4 Internal Not collected Primary 1.30 (1300) 29 to 116 (2 to 8) – 0.93 (0.42) 10
V61R522A-Ax**** 1/4 External Not collected Primary 1.30 (1300) 26" Hg to 116 (-0.9 to 8) 44 to 116 (3 to 8) 0.93 (0.42) 10
V61R511D-Cx13AA 1/4 Internal Collected Secondary 1.30 (1300) 29 to 145 (2 to 10) – 0.71 (0.32) 11
V61R522D-Cx13AA 1/4 External Collected Secondary 1.30 (1300) 26" Hg to 145 (-0.9 to 10) 44 to 145 (3 to 10) 0.71 (0.32) 11
V62S511A-Ax**** 3/8 Internal Not collected Primary 2.60 (2600) 29 to 116 (2 to 8) – 1.59 (0.72) 10
V62S522A-Ax**** 3/8 External Not collected Primary 2.60 (2600) 26" Hg to 116 (-0.9 to 8) 44 to 116 (3 to 8) 1.59 (0.72) 10
V62S511D-Cx13AA 3/8 Internal Collected Secondary 2.60 (2600) 29 to 145 (2 to 10) – 1.36 (0.62) 11
V62S522D-Cx13AA 3/8 External Collected Secondary 2.60 (2600) 26" Hg to 145 (-0.9 to 10) 44 to 145 (3 to 10) 1.36 (0.62) 11
14 4 2
12
5 1 3
