V60 Series
Littleton, CO USA Phone: 303-794-2611 www.norgren.com VAL-3-5
V60PA11A-Ax**** 1/8 Internal Not collected Primary 0.50 (500) 29 to 116 (2 – 8) – 0.75 (0.34) 7
V60PA11D-Cx13AA 1/8 Internal Collected Secondary 0.50 (500) 29 to 145 (2 – 10) – 0.53 (0.24) 8
V61RA11A-Ax**** 1/4 Internal Not collected Primary 0.95 (950) 29 to 116 (2 – 8) – 0.95 (0.43) 7
V61RA11D-Cx13AA 1/4 Internal Collected Secondary 0.95 (950) 29 to 145 (2 – 10) – 0.73 (0.33) 8
V62SA11A-Ax**** 3/8 Internal Not collected Primary 1.90 (1900) 29 to 116 (2 – 8) – 0.73 (0.33) 7
V62SA11D-Cx13AA 3/8 Internal Collected Secondary 1.90 (1900) 29 to 145 (2 – 10) – 1.39 (0.63) 8
V60PB11A-Ax**** 1/8 Internal Not collected Primary 0.50 (500) 29 to 116 (2 – 8) – 0.75 (0.34) 7
V60PB11D-Cx13AA 1/8 Internal Collected Secondary 0.50 (500) 29 to 145 (2 – 10) – 0.53 (0.24) 8
V61RB11A-Ax**** 1/4 Internal Not collected Primary 0.95 (950) 29 to 116 (2 – 8) – 0.95 (0.43) 7
V61RB11D-Cx13AA 1/4 Internal Collected Secondary 0.95 (950) 29 to 145 (2 – 10) – 0.73 (0.33) 8
V62SB11A-Ax**** 3/8 Internal Not collected Primary 1.90 (1900) 29 to 116 (2 – 8) – 1.61 (0.73) 7
V62SB11D-Cx13AA 3/8 Internal Collected Secondary 1.90 (1900) 29 to 145 (2 – 10) – 1.39 (0.63) 8
V60PC11A-Ax**** 1/8 Internal Not collected Primary 0.50 (500) 29 to 116 (2 – 8) – 0.75 (0.34) 7
V60PC11D-Cx13AA 1/8 Internal Collected Secondary 0.50 (500) 29 to 145 (2 – 10) – 0.53 (0.24) 8
V61RC11A-Ax**** 1/4 Internal Not collected Primary 0.95 (950) 29 to 116 (2 – 8) – 0.95 (0.43) 7
V61RC11D-Cx13AA 1/4 Internal Collected Secondary 0.95 (950) 29 to 145 (2 – 10) – 0.73 (0.33) 8
V62SC11A-Ax**** 3/8 Internal Not collected Primary 1.90 (1900) 29 to 116 (2 – 8) – 1.61 (0.73) 7
V62SC11D-Cx13AA 3/8 Internal Collected Secondary 1.90 (1900) 29 to 145 (2 – 10) – 1.39 (0.63) 8
2 x 3/2 Solenoid Pilot Valves
14 4 10
5 1
10 2 12
3
10 4 14
5
1
12
3
2 10
10 4 14
5
1
10 2 12
3
NC/NC
NO/NO
NO/NC
Symbol Model Port size Pilot exhaust Pilot supply Solenoid
variant Flow Cv
(l/min) Operating
pressure (bar) Pilot pressure
(bar) Dimensional
drawing no. lbs
(kg)
1 (+) 12 (Solenoid 2)
2 (–) 12 + 14
3 (+) 14 (Solenoid 1)
1 2
3
Double solenoid DIN EN 175 301-803 (DIN 43650 type C) 4 pin
Coil & voltage codes
Secondary
24 V d.c. 13 A 2 W
VVoollttaaggee Coil code Power inrush/hold
S Syym mbbooll Plug no. Function Actuation
12 V d.c. 12J 2 W 54469-01
24 V d.c. 13J 2 W 54469-02
24 V 50/60 Hz 14J 4/2.5 VA 54469-04
48 V 50/60 Hz 16J 4/2.5 VA 54469-07
110/120 V 50/60 Hz 18J 4/2.5 VA 54469-03
220/240 V 50/60 Hz 19J 6/5 VA 54469-08
VVoollttaaggee Coil code Power inrush/hold Model
Voltage tolerance: ±10%
Rating: 100% E.D.
Protection class: IP 65 with sealed plugs (ISO 6952)
Electrical details
Plug configuration, valve side/twin pilot
Primary (22 mm coil industrial standard)
3-Pin Industrial Standard 22mm
A = no connector
B = Cable grip 0-240Vac/Vdc
54934-01
C = 6 ft molded cable, 0-240Vac/Vdc 54934-21
H = Cable grip w/indicator light 24Vdc 54934-08
J = Cable grip w/indicator light 120Vac 54934-02
Z = 1/2" Conduit 0-240Vac/Vdc 54934-05
5 = 6 ft molded cable w/indicator light, surge suppression, 24Vac/Vdc 54934-30
6 = 6 ft molded cable w/indicator light, 120Vac 54934-35
4-Pin Connector
A = no connector
Y = 4–pin cable grip 0-240Vac/Vdc
0588666
X = 4–pin 10’ molded cable 0-240Vac/Vdc 0102144
Connectors
**** Insert coil connector code from tables below.
For manual override options, substitute ‘x’ as follows:
1 = without manual override NC/NC = Both valves normally closed
2 = locking NO/NO = Both valves normally open
3 = non-locking NO/NC = 1 valve normally open, 1 valve normally closed
