Norgren V41 Mini ISO Star Valves - Manual (Page 4)

VAL- 77
V
AL
VES
Norgren.com/usa – 303.794.2611 – [email protected]
Single Station Sub-base Modular Sub-base Side Modular Sub-base Side* Modular Sub-base Side Modular Sub-base Side*
Side Ported w/ Pilot Ports Ported w/o Pilot Ports Ported with Pilot Ports Ported (PIF) w/o Pilot Ports Ported (PIF) with Pilot Ports
V70401-P5B (1/8 NPTF) V70425-P5F (1/8 NPTF) V70426-P5F (1/8 NPTF) V70425-15F (ø1/4”) V70426-15F (ø1/4”)
V70401-A5B (G1/8) V70425-A5F (G1/8) V70426-A5F (G1/8) V70425-85F (ø8 mm) V70426-85F (ø8 mm)
V70425-65F (ø6 mm) V70426-65F (ø6 mm)
Bases
Sandwich Plate with additional
Intermediate Supply/Exhaust Module Single Valve Shut-Off Plate Pressure Port 1 Single Pressure Regulator Plate Double Pressure Regulator Plate
V70429-P5O (1/8 NPTF) V70430-K5O (Port 1 open/closed) V70435-P50 (1/8 NPTF) V70427-K51 (Port 1 reg.) V70427-K54 (Ports 2+4 reg.)
V70429-A5O (G1/8) V70427-K52 (Port 2 reg.)
V70427-K53 (Port 4 reg.)
Flow Control Plate Blanking Plate for unused Station DIN EN 50 022 rail (1 metre) DIN-rail Mounting Kit Blanking Disk to Modular Sub-base
V70428-K5O (Ports 3+5 reg.) V70400-K5O V10009-C00 (35x7.5mm) V70531-KA0 V70422-K50 (1 each) (Ports 1,3,5)
V10592-C01 (35x15mm) V70423-K50 (1 each) (Ports 12+14)
Blanking Plug for Manual Override Set-Up Kit Transition Plate #18 mm ➞ #26 mm Transition Plate #18 mm ➞ #26 mm
w/ supply and exhaust ports
Fixed Length Sub-base V70532-K00 V70436-K00 V70436-R00 (1/4 NPTF)
V70421-K50 (Ports 1,3,5) V70436-B00 (G1/4)
V40/V41 Mini ISO Star Valves
2x3/2, 5/2 and 5/3, Solenoid and Pilot Actuated ISO 15407-1 / VDMA 24 563 Size 18 mm
End Plate Kit Double Station Modular Sub-base End Plate Kit with 2 Side Ported Fixed Length Sub-base
End Ported Side Ported without Pilot Ports Valve Stations without Pilot Ports Bottom Ported
V70424-R5C (1/4 NPTF) V70432-P5F (1/8 NPTF) V70431-P5F (1/4, 1/8 NPTF) V704**-P50 (1/8 NPTF)
V70424-B5C (G1/4) V70432-A5F (G1/8”) V70431-A5F (G1/4, G1/8) ** = 02,04,06,08,10,12 stations
*Use with air pilot valves
Model Spool Valve Function Operator Return Flow Operating Pres. Pilot Pres. Weight Spares Kit
14 12 Cv (psig) (psig) (lb.)
V405633A-X0020 Gl APB Air Air 0.62 26" Hg - 232 29 - 232 0.24 V70441-K5O
V415633A-X0020 Ss APB Air Air 0.69 26" Hg - 145 36 - 145 0.26 V70444-K5O
V405733A-X0020 Gl COE Air Air 0.62 26" Hg - 232 29 - 232 0.24 V70441-K5O
V415733A-X0020 Ss COE Air Air 0.69 26" Hg - 145 36 - 145 0.26 V70445-K5O
V405833A-X0020 Gl COP Air Air 0.62 26" Hg - 232 29 - 232 0.24 V70441-K5O
V415833A-X0020 Ss COP Air Air 0.69 26" Hg - 145 36 - 145 0.26 V70446-K5O
5/3 Air Pilot Actuated Valves
4 2
12 14
3 5
1
4 2
12 14
3 5
1
4 2
12 14
3 5
1
