Table 1
**Voltage Codes and Spare Pilot Valves
Voltage
Code
Power Inrush / Hold
Pilot Valve Part.-no.
12 V d.c.
12
1.2 W
VZC7L2C1-C312A
24 V d.c.
13
1.2 W
VZC7L2C1-C313A
24 V 50/60 Hz.
14
2.1 / 1.5 VA
VZC7L2C1-C314A
48 V 50/60 Hz
16
2.1 / 1.5 VA
VZC7L2C1-C316A
110 V d.c.
17
1 W
VZC7L2C1-C317A
115 V 50/60 Hz
18
2.1 / 1.5 VA
VZC7L2C1-C318A
230 V 50/60 Hz
19
2.1 / 1.5 VA
VZC7L2C1-C319A
Other voltages available on request.
Spare pilot valves are delivered with mounting screws.
Table 2
†Connector Codes and Part Number
Code Part Number
A = Solenoid without connector
B = Cable grip
V10027-D00
C = 10 ft. molded cable, 0-240 VAC/VDC
V10013-D03
H = Cable grip w/indicator light, 24 VAC/VDC
V10012-D13
J = Cable grip w/indicator light, 120 VAC/VDC
V10012-D18
5 = 10 ft. molded cable with indicator light, surge suppression, 24 VAC/VDC
V10014-D03
6 = 10 ft. molded cable with indicator light, 110V/50 Hz-120V.60Hz
V10015-D03
V40/V41 Mini ISO Star Valves
2x3/2, 5/2 and 5/3, Solenoid and Pilot Actuated ISO 15407-1 / VDMA 24 563 Size 18 mm
Model
Spool
Pilot
Pilot
Operator
Return
Flow
Operating
Pilot
Weight
Repair Kit
Techn.
Supply
Exhaust
14
12
Cv
Pres. (psig)
Pres. (psig)
lb.
V405513D-C3**†
Gl
Internal
Collected
Solenoid
Air Spring
0.58
14.5 - 145
-
0.26
V70440-K5O
V415513D-C3**†
Ss
Internal
Collected
Solenoid
Air Spring
0.66
14.5 - 145
-
0.29
V70442-K5O
V405523D-C3**†
Gl
External
Not collected
Solenoid
Air Spring
0.58
26" Hg - 232
14.5 - 145
0.26
V70440-K5O
V415523D-C3**†
Ss
External
Not collected
Solenoid
Air Spring
0.66
26" Hg - 145
14.5 - 145
0.29
V70442-K5O
V405516D-C3**†
Gl
Internal
Collected
Solenoid
Spring & air
0.58
23.2 - 145
-
0.29
V70440-K5O
V415517D-C3**†
Ss
Internal
Collected
Solenoid
Spring
0.66
29 - 145
-
0.29
V70442-K5O
V405526D-C3**†
Gl
External
Not collected
Solenoid
Spring & air
0.58
26" Hg - 232
23.2 - 145
0.29
V70440-K5O
V415527D-C3**†
Ss
External
Not collected
Solenoid
Spring
0.66
26" Hg - 145
29 - 145
0.29
V70442-K5O
V405511D-C3**†
Gl
Internal
Collected
Solenoid
Solenoid
0.58
29 - 145
-
0.40
V70441-K5O
V415511D-C3**†
Ss
Internal
Collected
Solenoid
Solenoid
0.66
29 - 145
-
0.40
V70443-K5O
V405522D-C3**†
Gl
External
Not collected
Solenoid
Solenoid
0.58
26" Hg - 232
29 - 145
0.40
V70441-K5O
V415522D-C3**†
Ss
External
Not collected
Solenoid
Solenoid
0.66
26" Hg - 145
29 - 145
0.40
V70443-K5O
V405591D-C3**†
Gl
Internal
Collected
Solenoid (priority)
Solenoid
0.58
29 - 145
-
0.40
V70441-K5O
V405592D-C3**†
Gl
External
Not collected
Solenoid (priority)
Solenoid
0.58
26" Hg - 232
29 - 145
0.40
V70441-K5O
5/2 Solenoid Pilot Actuated Valves
2x3/2 Solenoid Pilot Actuated Valves (Softseal Spool only)
Model
Function
Pilot
Pilot
Actuation
Flow
Operating
Pilot
Weight
Repair Kit
2x3/2
Supply
Exhaust
3/2 Function
Cv
Pres. psig
Pres. (psig)
lb.
V415A11D-C3**†
NC
Internal
Collected
Sol/Spring
0.62
36 - 145
-
0.40
V70447-K5O
V415A22D-C3**†
NC
External
Not Collected Sol/Spring
0.62
0 - 145
24.7+(0.35 x op.press.)
0.40
V70447-K5O
V415B11D-C3**†
NO
Internal
Collected
Sol/Spring
0.62
36 - 145
-
0.40
V70448-K5O
V415B22D-C3**†
NO
External
Not Collected
Sol/Spring
0.62
0 - 145
24.7+(0.35 x op.press.)
0.40
V70448-K5O
V415C11D-C3**†
NO/NC
Internal
Collected
Sol/Spring
0.62
36 - 145
-
0.40
V70449-K5O
V415C22D-C3**†
NO/NC
External
Not collected
Sol/Spring
0.62
0 - 145
24.7+(0.35 x op.press.)
0.40
V70449-K5O
** Insert voltage code from Table 1 “Voltage Codes and Spare Pilot Valves”.
† Add connector code from Table 2 “Connector Codes and Part Number”.
